CPC Definition - Subclass B65H

Last Updated Version: 2019.01
HANDLING THIN OR FILAMENTARY MATERIAL, e.g. SHEETS, WEBS, CABLES
Definition statement

This place covers:

Handling aspects of general interest relating to thin material in the form of "separate articles" such as sheets, signatures, envelopes, blanks, cards, and thin piles thereof.

Handling aspects of general interest relating to thin material in the form of "continuous articles" such as webs, tapes, and films

Filamentary material such as threads, wires, ropes, cables, and hoses, and cover only methods or devices of general application or interest.

The coverage of the subclass can generally be divided into:

Sheets

Feeding to processes:

Feeding from processes:

Particular handling processes or apparatus therefor:

Relating both to sheet and/or web handling aspects:

Webs:

Feeding out, taking up:

Particular handling processes or apparatus therefor:

Relating both to sheet and/or web handling aspects:

Filamentary material:

Relationships with other classification places

In general the subclass does not cover subject-matter (methods or devices) which are more intimately associated with operations, or means for performing such operations, on the thin or filamentary material than with the handling of the material per se. Such subject-matter is classified in subclasses relevant for the respective operations or means (see further explanation in "Special Rules of Classification", Note 3a and 3b). Such relevant subclasses are in particular:

  • Bandages or dressings A61F 13/00;
  • Card games appurtenances A63F 1/06;
  • Cleaning travelling work, e.g. webs, by methods involving the use of tools, brushes or like members B08B 1/02;
  • Devices accepting or dispensing paper currency, e.g. depositing machines; Automatic teller machines (ATM) G07D 11/00, G07F 19/20;
  • Conveying or guiding webs through rotary printing presses or machines B41F 13/02;
  • Conveying record carriers from one station to another G06K 13/00;
  • Composing machines B41B 21/32;
  • Counting of objects carried by a conveyor ; objects in a stack G06M 7/00 and G06M 9/00;
  • Feeding, positioning or storing devices, combined with, or arranged in, or specially adapted for use in connection with, apparatus for working or processing sheet metal without essentially removing material B21D 43/00;
  • Film-handling mechanisms in photographic machines B41B 15/32;
  • Film-strip handling or handling of pictures in apparatus for taking photographs or for projecting or viewing them G03B 1/00 and G03B 27/00;
  • Handling fabrics, fibres, yarns or other material in long lengths in drying apparatus F26B 13/00;
  • Handling for shaping or joining of plastics, for shaping of substances in a plastic state in general or for after-treatment of shaped products, e.g. feeding the material to be shaped B29C 31/00;
  • Handling intimately associated with electrographic processes using a charge pattern G03G 15/60, G03G 15/65;
  • Handling of copy- or impression-transfer material in typewriters or selective printing mechanisms B41J 11/00 - B41J 17/00;
  • Handling of labels in labelling or tagging apparatus B65C;
  • Handling of sheets or webs in apparatus for, or methods of, packaging articles, not of interest apart from their application in packaging machines B65B;
  • Handling relating to permanently attaching together sheets, quires, or signatures B42B;
  • Handling sheets in book-binding B42C;
  • Handling sheets intimately associated with inserting documents into envelopes B43M 3/00, B43M 5/00 and B43M 7/00;
  • Handling sheets not of interest apart from its use in systems for transmission or reproduction of pictures or patterns not varying in time, e.g. facsimile transmission H04N 1/00;
  • Handling sheets or webs in apparatus or devices for manifolding, duplicating or printing for office or other commercial purposes, or on addressing machines or like series-printing machines B41L;
  • Handling means for copy matter in stamping or numbering apparatus or devices B41K 3/44;
  • Information storage based on relative movement between record carrier and transducer, involving handling record carriers for recording or reproducing G11B 15/00 - G11B 19/00, G11B 23/00 and G11B 25/00;
  • Machines for severing e.g. by cutting, perforating, punching, stamping-out B26D;
  • Machines for Perforating, punching, stamping-out other than by cutting B26F;
  • Machines for winding capacitors H01G 13/02;
  • Making boxes, cartons, envelopes or bags B32B;
  • Manufacturing coils for magnets, inductances, transformers, by winding H01F 41/06;
  • Means for automatic feeding of electrodes for spot or seam welding or cutting B23K 9/12;
  • Measuring arrangements characterised by the use of optical means G01B 11/00;
  • Metal rolling involving guiding, conveying or accumulating easily-flexible work, e.g. wire, sheet metal bands, in loops or curves B21B 41/00;
  • Postal sorting, similar sorting of documents, e.g. cheques B07C;
  • Rolls, drums, discs or the like F16C 13/00;
  • Spinning, weaving, braiding, lace-making, knitting, sewing, making ropes or cables D01 - D07;
  • Supports or handling devices for wafers for manufacturing semiconductor components H01L 21/67;
  • Transferring webs from wet ends to press sections in paper-making D21F 2/00;
  • Transport or storage devices, conveyor s for objects in general B65G;
  • Testing or determining the identity or genuineness of paper currency G07D 7/00;
  • Winding-up, coiling, winding-off or temporarily accumulating metal wire, metal band or other flexible metal material, characterised by features relevant to metal processing only, other than by rolling B21C 47/00 and B21C 49/00;
  • Winding or stacking hides or leather in machines or devices for manufacturing leather C14B 1/62;
References
Application-oriented references

Examples of places where the subject matter of this place is covered when specially adapted, used for a particular purpose, or incorporated in a larger system:

Postal sorting, similar sorting of documents, e.g. cheques

B07C

Cleaning travelling work, e.g. webs, by methods involving the use of tools, brushes or like members

B08B 1/02

Metal rolling involving guiding, conveying or accumulating easily-flexible work, e.g. wire, sheet metal bands, in loops or curves

B21B 41/00

Winding or unwinding metal band or like flexible metallic material during manufacture

B21C

Winding-up, coiling, winding-off or temporarily accumulating metal wire, metal band or other flexible metal material, characterised by features relevant to metal processing only, other than by rolling

B21C 47/00, B21C 49/00

Feeding, positioning or storing devices, combined with, or arranged in, or specially adapted for use in connection with, apparatus for working or processing sheet metal without essentially removing material

B21D 43/00

Working or processing wire

B21F, B21G

Means for automatic feeding of electrodes for spot or seam welding or cutting

B23K 9/12

Handling for shaping or joining of plastics, for shaping of substances in a plastic state in general or for after-treatment of shaped products, e.g. feeding the material to be shaped

B29C 31/00

Film-handling mechanisms in photographic composing machines

B41B 15/32, B41B 21/32

Conveying or guiding webs through rotary-printing presses or machines

B41F 13/02

In selective printing mechanisms

B41J

Handling of copy- or impression-transfer material in typewriters or selective printing mechanisms

B41J 11/00- B41J 17/00

Means for handling copy matter in stamping or numbering apparatus or devices

B41K 3/44

Handling sheets or webs in apparatus or devices for manifolding, duplicating or printing for office or other commercial purposes, or on addressing machines or like series-printing machines

B41L

Handling relating to permanently attaching together sheets, quires, or signatures

B42B

Handling sheets in book-binding

B42C

Unwinding, paying-out, forwarding, or winding ropes or cables in load-moving apparatus

B61B, B65G, B66

Handling of sheets or webs in apparatus for, or methods of, packaging articles, not of interest apart from their application in packaging machines

B65B

Handling of labels in labelling or tagging apparatus

B65C

Winding or stacking hides or leather in machines or devices for manufacturing leather

C14B 1/62

Spinning, weaving, braiding, lace-making, knitting, sewing, making ropes or cables

D01- D07

Creels, warping, beaming, or leasing machines or methods for textile manufacturing purposes

D02H

Transferring webs from wet ends to press sections in paper-making

D21F 2/00

Handling fabrics, fibres, yarns or other material in long lengths in drying apparatus

F26B 13/00

Film-strip handling or handling of pictures in apparatus for taking photographs or for projecting or viewing them

G03B

Winding, unwinding, or feeding tape to, in, or from, information-processing apparatus

G06, G11B

Conveying record carriers from one station to another

G06K 13/00

Counting of flat articles, e.g. sheets, carried by a conveyor

G06M 7/00

Information storage based on relative movement between record carrier and transducer, involving handling record carriers for recording or reproducing

G11B 15/00- G11B 19/00, G11B 23/00, G11B 25/00

Manufacturing coils for magnets, inductances, transformers, by winding

H01F 41/06

Machines for winding capacitors

H01G 13/02

Sheet handling not of interest apart from its use in systems for transmission or reproduction of pictures or patterns not varying in time, e.g. facsimile transmission.

H04N 1/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Manipulators

B25J

Special rules of classification

For filamentary material the following table shall be used as Informative Reference to identify overlapping classes to be searched in the field of textile.


The preceding image includes references to B65H 49/02, B65H 49/18, B65H 51/00, B65H 51/20, B65H 54/26, B65H 54/28, B65H 54/34, B65H 54/70, B65H 45/02, B65H 54/76, B65H 57/00, B65H 59/00, B65H 61/00, B65H 63/00, B65H 67/00, B65H 69/00, B65H 71/00, B65H 49/36, B65H 54/54, B65H 75/24, B65H 81/08, D01D 7/02, D01D 5/096, D01G 25/00, D01G37/00, D01H 1/18, D01H 13/00, D01H 1/36, D01H 13/06, D01H 1/38, D01H 11/00, D01H 7/18, D01H 13/02, D01H 13/04, D01H 13/10, D01H 13/14, D01H 13/32, D01H 9/00, D01H 4/48, D01H 15/00, D01H 13/30, D01H 7/16, D02G 1/14, D02G 3/36, D02H 1/00, D02H 13/12, D02H 13/22, D02H 13/02, D02J 13/00, D03D 39/06, D03D 47/34, D03D 49/16, D03D 49/04, D03D 51/18, D03J 1/00, D03J 1/16, D03J 1/02, D03J 1/04, D04B 15/38, D04B 15/48, D04B 35/32, D04B 15/54, D04B 15/44, D04B 35/10, D04B 35/24, D04H 1/70, D05C 15/18, D05C 11/08, D06B 23/02.

  • The following IPC groups are not used in the internal classification scheme. Subject matter covered by these groups is classified in the following internal groups:

B65H19/16/IPC covered by B65H 19/1889/EC

B65H35/07/IPC covered by B65H 35/0006/EC;

Note 1:

The B65H scheme is applied in combination with the B65H scheme for classifying complementary information which is judged to be of particular interest. The B65H scheme is divided into the following themes:

B65H 2701/17 - Nature of material

B65H 2701/18 - Form of handled article or web

B65H 2701/19 - Specific article or web

B65H 2801/00 - Application field

however, if for example a document already has a B07C symbol there is no need for adding B65H 2701/1916 "envelopes or articles of mail";

if for example a document already has a H04N symbol there is no need for adding B65H 2801/39 "Scanning"

Indexing codes of groups B65H 2511/00 - B65H 2519/00 and B65H 2701/13 can be combined with the following symbols relating to additional characteristics or to further specify the information. The additional symbols have the meanings indicated below:

  • B65H 2220/01 - Indicates that the first Indexing Code relates to an entity as a function of which control, adjustment or change is performed (input);
  • B65H 2220/02 - Indicates that the first Indexing Code relates to an entity which is controlled, adjusted or changed by a control process (output);
  • B65H 2220/03 - Indicates that the first Indexing Code relates to an entity which is measured, estimated, evaluated, calculated or determined but which is not adjusted or changed by the control process per se;
  • B65H 2220/04 - For distinguishing "adjusting" from controlling i.e. manual adjustments;
  • B65H 2220/08 - For distinguishing changing an entity in function of another entity purely by mechanical means i.e. no electronics involved;
  • B65H 2220/09 - Indicates that several of an entity are present;
  • B65H 2220/11 - Indicates that the code exclusively relates to machine elements, (to be combined with one of the indicators B65H 2220/01 - B65H 2220/09).

B65H 2220/09 can also be combined with other symbols when it is important to mark that several of an entity are present

Indexing Codes of groups B65H 2301/447 can be combined with additional symbols B65H 2220/01 and/or B65H 2220/02 to indicate additional characteristics. The addition has the following meaning:

  • B65H 2220/01 - For indicating a transport device whose receiving section is involved in the transfer;
  • B65H 2220/02 - For indicating a transport device whose delivering section is involved in the transfer;
  • B65H 2220/01, B65H 2220/02 - For indicating a transport device whose both receiving and delivering section are involved in the transfer;

Examples relating to the additional symbols:

If the device and/or method for controlling is not the main but only an additional aspect of the invention the B65H symbols can be given without the symbol B65H 7/02

If the rotational speed of the separator is changed manually by the operator the last code should be B65H 2513/11+ B65H 2220/04

Only the following B65H entries should always be used for the B65H groups related to filamentary material:

Note 2:

If it is judged that handling aspects are relevant for both articles being fed to a process and for articles being fed from a process, they should be classified in the groups concerning "feeding to processes" as well as in the groups concerning "feeding from processes" unless precedence notes dictate otherwise.

Note 3a:

When judging whether subject-matter is to be considered as being more "intimately associated " with operations on the thin or filamentary material than with the handling of the material per se, it should be judged whether the handling aspect, in particular the handling problem to be solved, could be understood per se without referring to the particular operation, or in other words, whether the handling of the material is technically inseparable from the respective operation. If the handling aspect is clearly inseparable from the operation, then this aspect should be classified only in the subclass relevant for that operation. If the handling aspect is clearly separable from the operation, then the aspect should only be classified in B65H (see examples type A).

Note 3b:

In many cases, however, such a clear distinction concerning the technical separabillity cannot be made. In such cases, the subject-matter should be classified both in B65H and the subclass concerning the operation action per se. If it is judged, that the handling aspects to a large extent are technically separable from the operation, but the operation nevertheless has some bearing on the handling, then the subject-matter should be classified in the relevant B65H groups combined with an B65H 2801/00 symbol indicating the operation in the form of an application field (see example type B).

  • Example type A:
  • A document disclosing that the feeding speed of a piece of paper in an ink jet printer is controlled as a function of the ongoing printing operation should be classified in B41J and not in B65H.
  • Example type B:
  • A document discloses handling means for replenishing the pile of paper sheets from which sheets are continuously separated and fed to an off-set printing machine without having to stop the printing machine. The printing process as such only has a bearing on the replenishing means (handling means) in as much as the size of the handling means is dictated by the size of the off-set printing machine. Such a document should be classified in B65H 1/30 together with the B65H 2801/21 symbol for "industrial size printers, e.g. rotary printing press".
Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Package

A mass of filamentary material, formed by coiling, depositing, or winding, with or without a supporting core or former or an enclosing container or receptacle.

Handling

Separating, orientating/positioning, feeding, gathering, collecting, storing, folding (other than in the manufacture of products), unwinding, and winding.

Filamentary material

Includes thread, wires, ropes, cables, and hoses.

Thin material

Sheets, signatures, envelopes, blanks, and thin piles thereof (hereinafter referred to as "articles"), and webs, tapes, and films, e.g. of paper, fabric, metal foil, or plastics.

Supports or magazines for piles from which articles are to be separated (carriers used for associating, collating, or gathering articles B65H 39/00)
Definition statement

This place covers:

Supports or magazines or the like for completely separate but stacked or piled articles, such as for example a pile of A4 size paper sheets. A cassette for tickets which are semi attached to each other, so that a second ticket follows automatically when pulling the first ticked, is for example not covered.

References
Limiting references

This place does not cover:

Supports or magazines intimately associated with piling of articles

B65H 31/00

Holders or dispensers for towels or tissues

A47K 10/00

Supports for sheets united without binding to form pads or blocks

B42D 5/00

Articles in a strip, to be separated by tearing, severing or cutting from the strip, for example lottery tickets

G07F 11/00

Special rules of classification
adapted to support articles on edge
Definition statement

This place covers:

This subclass/group covers:Supports which carry piles in such a way that the weight of the pile is mainly supported by the edges of the articles. This is for example the case where a support which carries a square pile of articles on their surfaces is tilted from the horizontal to an angle more than 45 degrees. The group does not cover the cases where the weight of the pile must be said to be carried equally by the edges and the surfaces of the articles. e.g. cases where a support which carries a square pile of articles on their surfaces is tilted from the horizontal to an angle of exactly 45 degrees. These cases are covered by B65H 1/04.

See examples below:



{with non-controlled means for advancing the pile to present the pile to the separating device, e.g. weights or spring}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

See the spring 25 pressing the support 21


{with controlled positively-acting mechanical devices for advancing the pile to present the articles to the separating device}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

Mechanical device (8,9,25,26) drives the pusher (10,11)


Special rules of classification


{Support fully or partially removable from the handling machine, e.g. cassette, drawer}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Copy medium cassettes for apparatuses for electro photographic processes

G03G 2215/00383

Cassettes for paper currency

G07D 11/12

adapted to support articles substantially horizontally, e.g. for separation from top of pile
Definition statement

This place covers:

  • Supports which carry piles in such a way that the weight of the pile is mainly supported by the surfaces of the articles. This is for example the case where a support which carries a square pile of articles on their surfaces is tilted from the horizontal to an angle less than 45 degrees.
  • Cases where the weight of the pile must be said to be carried equally by the edges and the surfaces of the articles. e.g. cases where a support which carries a square pile of articles on their surfaces is tilted from the horizontal to an angle of exactly 45 degrees.


References
Limiting references

This place does not cover:

Supports which carry piles in such a way that the weight of the pile is mainly supported by the edges of the articles

B65H 1/02 - B65H 1/027

for separation from bottom of pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with means for advancing the articles to present the articles to the separating device {(B65H 1/02 takes precedence)}
References
Limiting references

This place does not cover:

Supports or magazines for piles from which articles are to be separated adapted to support articles on edge

B65H 1/02

Informative references

Attention is drawn to the following places, which may be of interest for search:

comprising weights {(B65H 1/022 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

See the weight element (41,41b)


References
Limiting references

This place does not cover:

Supports or magazines for piles from which articles are to be separated with non-controlled means for advancing the pile to present the pile to the separating device

B65H 1/022

comprising spring {(B65H 1/022 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



References
Limiting references

This place does not cover:

Supports or magazines for piles from which articles are to be separated with non-controlled means for advancing the pile to present the pile to the separating device

B65H 1/022

comprising positively-acting mechanical devices {(B65H 1/025 takes precedence)}
Definition statement

This place covers:

Specific mechanical /constructional details of the devices. e.g. the mechanical structure of the device is the main aspect.

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Supports or magazines for piles from which articles are to be separated with controlled positively-acting mechanical devices for advancing the pile to present the articles to the separating device

B65H 1/025

Rollers or like rotary separators cooperating with means for automatically separating the pile from roller or rotary separator after a separation step

B65H 3/0607

Informative references

Attention is drawn to the following places, which may be of interest for search:

Special rules of classification

For specifically described control procedures the corresponding B65H 2511/00 - B65H 2557/62 codes and B65H 7/00 scheme should be applied. For example:

comprising pneumatic or hydraulic means {(B65H 1/18, B65H 1/20 take precedence)}
References
Limiting references

This place does not cover:

Means for advancing the articles to present the articles to the separating device controlled by height of pile

B65H 1/18

Means for advancing the articles to present the articles to the separating device controlled by weight of pile; Floating arrangements

B65H 1/20

controlled by weight of pile; Floating arrangements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


moving in direction of plane of articles, e.g. for bodily advancement of fanned-out piles
Definition statement

This place covers:

Advancement of fanned-out piles without reversing the articles. For example from overlapped to underlapped

Illustrative examples of subject matter classified in this group:


References
Limiting references

This place does not cover:

With means for replenishing the pile during continuous separation of articles therefrom

B65H 1/30

{Round stack feeders}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with auxiliary supports to facilitate introduction or renewal of the pile
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Auxiliary supports for keeping the pile in the separation process during introduction of a new pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Support fully or partially removable from the handling machine, e.g. cassette, drawer (B65H 1/027 takes precedence)}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Support fully or partially removable from the handling machine, e.g. cassette, drawer for articles supported on the edge

B65H 1/027

Informative references

Attention is drawn to the following places, which may be of interest for search:

Copy medium cassettes for apparatuses for electro photographic processes

G03G 2215/00383

Cassettes for paper currency

G07D 11/12

Special rules of classification

Details concerning arrangement or construction are classified by using symbols from B65H 2405/10 - B65H 2405/30:

compartmented to receive piles side-by-side
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Special rules of classification

Details concerning arrangement or construction are classified by using symbols from B65H 2405/10 - B65H 2405/30.

with means for replenishing the pile during continuous separation of articles therefrom {(B65H 1/22 takes precedence)}
Definition statement

This place covers:

The concept "replenishing the pile" consists in supplying complete piles or stacks to the support or magazine.



References
Limiting references

This place does not cover:

Means for advancing the articles to present the articles to the separating device moving in direction of plane of articles

B65H 1/22

Combinations of piling and depiling operations e.g. performed simultaneously, of interest apart from the single operation of piling or depiling as such

B65H 83/00

Special rules of classification

Supplying individual articles, either continuous or discontinuous to the pile during continuous separation therefrom: B65H 83/02

Separating articles from piles (associating, collating, or gathering articles B65H 39/00; machines for separating superposed webs B65H 41/00; unpiling thin material combined with folding B65H 45/26; combinations of piling and depiling operations, of interest apart from the single operation of piling or depiling B65H 83/00 {, B07C 1/02, G07D 11/50 })
Definition statement

This place covers:

The various arrangements for separating (i.e. removing) articles from piles to be fed to processing machines (e.g. printers) and the associated mechanisms for ensuring that the separation is performed reliably, e.g. only one article is removed each time.

References
Limiting references

This place does not cover:

The reverse operation (i.e. stacking articles in piles)

B65H 39/00

Separating superposed webs

B65H 41/00

Separating from piles in combination with folding

B65H 45/26

Combinations of piling and depiling operations, of interest apart from the single operation of piling or depiling

B65H 83/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Separating superposed articles transported in a stream

B65H 2301/44514

Forming postal articles into a stream:

B07C 1/02

Separation intimately linked with a paper currency sorting or counting machine

G07D 11/50

Special rules of classification

This main-group should be used only for subject-matter not being covered by any of its sub-groups.

using friction forces between articles and separator
Definition statement

This place covers:

Arrangements that use friction forces to separate the article from the pile.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Separating articles from bottom of pile of horizontal articles

B65H 2301/42322

Special rules of classification

This main-group should be used only for subject-matter not being covered by any of its sub-groups.

Manually powered apparatus, additionally classify also in B65H 2403/941.

Relevant UCLA: 271/42 reciprocating separators

Endless-belt separators
Definition statement

This place covers:

Arrangements using an endless belt wherein the separation force is created only by friction.

References
Limiting references

This place does not cover:

Perforated belts in which suction is used to enhance adherence of the article on the belt are covered by

B65H 3/12

Special rules of classification

This main-group should be used only for subject-matter not being covered by any of its sub-groups.

{separating from the bottom of the pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{for separating substantially vertically stacked articles}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(top view)

{separating from the top of a pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Rollers or like rotary separators {(B65H 3/42 takes precedence)}
Definition statement

This place covers:

Arrangements using rollers or similar rotating devices (e.g. spheres) wherein the separation force is created only by friction.

References
Limiting references

This place does not cover:

Rollers in which suction is used to enhance adherence of the article on the roller are covered by

B65H 3/10

Separating articles from piles by two or more separators mounted for movement with, or relative to, rotary or oscillating bodies

B65H 3/42

Special rules of classification

This main-group should be used only for subject-matter not being covered by any of its sub-groups.

{cooperating with means for automatically separating the pile from roller or rotary separator after a separation step}
Definition statement

This place covers:

Arrangements which allow the sheet support to move towards the separator roller for sheet separation and which move the sheets away from the separator roller once the separation step is completed.

Illustrative example of subject matter classified in this group:


Special rules of classification

If the subject-matter can be classified by the combination B65H 3/0607 and B65H 3/0661, then this takes precedence over B65H 1/025, see for example EP1681252A1.

The group takes precedence over B65H 1/14.

{reciprocating and rotatable in one direction only}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{acting at least during a part of each separation cycle on the articles in a direction opposite to the final separating direction}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{separating from the bottom of pile (B65H 3/0615, B65H 3/0623 take precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

For substantially vertical stacks with the separation roller below the stack additionally classify in B65H 3/0653.

References
Limiting references

This place does not cover:

Rollers or like rotary separators, reciprocating and rotatable in one direction only

B65H 3/0615

Rollers or like rotary separators acting at least during a part of each separation cycle on the articles in a direction opposite to the final separating direction

B65H 3/0623

{Construction of the rollers or like rotary separators (B65H 3/0615 takes precedence; construction of feed or guide rollers B65H 27/00)}
Definition statement

This place covers:

Construction of rollers or the like adapted for separating articles from piles

Illustrative example of subject matter classified in this group:


Relationships with other classification places

For details concerning, e.g.

  • materials used and their properties additionally classified in B65H 2401/00;
  • construction or arrangemnet of roller(s) additionally classified in B65H 2404/10;
  • surface of the elements in contact with the material forwarded or guided additionally classified in B65H 2404/50.
References
Limiting references

This place does not cover:

Rollers or like rotary separators, reciprocating and rotatable in one direction only

B65H 3/0615

For construction of rollers not limited to separation (e.g. feed or guide)

B65H 27/00

{Wave generation rollers, i.e. combing wheels}
Definition statement

This place covers:

Rollers with a plurality of surface elements which produce a pushing motion when hitting the article to be separated thereby creating a small wave in the article

Illustrative example of subject matter classified in this group:


{for separating substantially vertically stacked articles}
Definition statement

This place covers:

Separation from piles for which the weight of the pile is mainly supported by the edges of the articles. This is for example the case where a support which carries a square pile of articles on their surfaces is tilted from the horizontal to an angle more than 45 degrees.


Relationships with other classification places

For substantially vertical stacks with the separation roller below the stack additionally classify in B65H 3/063.

References
Limiting references

This place does not cover:

Rollers or like rotary separators for separating inclined-stacked articles with separator rollers above the stack

B65H 3/0661

{for separating inclined-stacked articles with separator rollers above the stack}
Definition statement

This place covers:

Arrangements wherein the stack is inclined, i.e. not completely horizontal (supported by the surface of the articles) or not completely vertical (supported by the edges of the articles).


Special rules of classification

If the subject-matter can be classified by the combination B65H 3/0607 and B65H 3/0661, then this take precedence over B65H 1/025, see for example EP1681252A1.

If the subject-matter can be classified by B65H 3/0661, then this take precedence over B65H 3/0653.

{Driving devices therefor}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

The group should always be used in combination with symbols in B65H 2403/00 concerning specific power transmission and driving means.

{with two or more separator rollers in the feeding direction}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{on moving support, e.g. pivoting, for bringing the roller or like rotary separator into contact with the pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Vacuum assisted separator rollers}
Definition statement

This place covers:

Arrangements in which suction is generated outside the roller, the roller body as such is not involved in generating vacuum

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Suction rollers, the roller body as such is involved in generating vacuum

B65H 3/10

using pneumatic force {(B65H 3/40, B65H 3/42 take precedence)}
Definition statement

This place covers:

Arrangements that use pneumatic forces to separate the article from the pile.

References
Limiting references

This place does not cover:

Separating articles from piles by two or more separators acting alternately on the same pile

B65H 3/40

Separating articles from piles by two or more separators mounted for movement with, or relative to, rotary or oscillating bodies

B65H 3/42

Special rules of classification

This group should be used only for subject-matter not being covered by any of its sub-groups.

{Suction grippers}
Definition statement

This place covers:

Arrangements with piles of articles standing on edge. Horizontally pilled articles are covered by the subgroups B65H 3/0816 and B65H 3/085.


Relationships with other classification places

For details of suction grippers additionally classify in subgroups of B65H 2406/34.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Suction grippers

B65H 3/08

{separating from the top of pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

For multi-axis actuating means additionally classify in subgroups of B65H 2555/30.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Pile of alternate articles

B65H 2701/18264

Devices for removing metal sheets from a stack

B21D 43/24

Destacking of articles by suction or magnetic devices

B65G 59/04

Apparatus for loading or unloading holders for X-ray films

G03B 42/045

{and acting on the rear part of the articles relatively to the final separating direction}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{and acting on the front part of the articles relatively to the final separating direction}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{this action resulting at least during a part of each separating cycle, in a movement of at least the front part of the articles in a direction opposite to the final separating direction}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{separating from the bottom of pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{this action resulting merely in a curvature of each article being separated (in combination with the use of screw or like separators B65H 3/28)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Separating articles from piles by screw or like separators

B65H 3/28

{the final separation being performed between rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

The front edge (10) of the article is separated by a suction element (2) whereafter a gripper (3) pulls out, that is finally separates, the whole article from the stack


{the final separation being performed by mechanical grippers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Elongated elements traversing pile and article to be separated (peeling)

B65H 2301/4233

{Construction of suction grippers or their holding devices}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Generating or controlling the depression (B65H 3/0883, B65H 3/14 take precedence; in response to abnormal circumstances B65H 7/16)}
Definition statement

This place covers:

Mechanical arrangements, different from just a connection to a general vacuum source, which create the depression e.g. the vacuum which is used by the separator to perform the separation

Illustrative example of subject matter classified in this group:


Relationships with other classification places

If the control is in response to abnormal circumstances additionally classify in B65H 7/16.

References
Limiting references

This place does not cover:

Construction of suction grippers or their holding devices

B65H 3/0883

Air blasts producing partial vacuum

B65H 3/14

Suction rollers
Definition statement

This place covers:

Rollers wherein the suction is generated by a vacuum inside the roller.


References
Limiting references

This place does not cover:

For vacuum assisted friction rollers

B65H 3/0692

{Suction tables}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

suction table 8 separates an article 1a by a reciprocating movement


{Suction bands or belts}
Definition statement

This place covers:

Arrangements with piles of articles standing on edge. Horizontally pilled articles are covered by the subgroups B65H 3/126 and B65H 3/128.


{separating from the bottom of pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{separating from the top of pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Air blasts producing partial vacuum
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


using magnetic force
Definition statement

This place covers:

Arrangements that use magnetic forces to separate the article from the pile (i.e. for articles with ferromagnetic properties).


using electrostatic force
Definition statement

This place covers:

Arrangements that use electrostatic forces (e.g. an electrostatically charged roller) to separate the article from the pile.


using adhesives
Definition statement

This place covers:

Arrangements that use adhesives to separate the article from the pile (e.g. by sticking the article on an adhesive separator).

by needles or the like engaging the articles
Definition statement

This place covers:

Arrangements using needles, or teeth-like elements or spike-like elements

Illustrative examples of subject matter classified in this group:



by pushers engaging the edges of the articles
Definition statement

This place covers:

Arrangements by pushers for separating single articles from piles.


{for separating a part of the pile, i.e. several articles at once}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the pile being pre-marked}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

The sheets 20" is marking the intended division of the pile


{the pile being off-set}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by separators engaging folds, flaps, or projections of articles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by screw or like separators
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by escapement devices (screw and like separators B65H 3/28); from staggered piles; from piles of articles having staggered formations, e.g. cuts or perforations
Definition statement

This place covers:

Devices which function as article retainers when inactive, and which produce a movement which separate one or more articles when activated.

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Separating articles from piles by screw or like separators

B65H 3/28

by elements, e.g. fingers, plates, rollers, inserted or traversed between articles to be separated and remainder of the pile (such elements acting only as supplementary devices to assist separation or prevent double feed B65H 3/50)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

If such elements act only as supplementary devices to assist separation or prevent double feed

B65H 3/50

{for separating a part of the pile, i.e. several articles at once}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the pile being pre-marked}
Definition statement

This place covers:

All forms of markings which make it possible to identify the intended division of the pile, for example coloured papers or strips or special shapes of the edges

Illustrative example of subject matter classified in this group:


{the pile being off-set}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Article-retaining devices controlling the release of the articles to the separators
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by separators moved in special paths, e.g. enclosing an area
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


the paths not enclosing an area
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

The separator 10 reciprocates along the broken line


by two or more separators acting alternately on the same pile (rotary or oscillating bodies carrying two or more separators B65H 3/42)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

For rotary of oscillating bodies carrying two or more separators

B65H 3/42

by two or more separators mounted for movement with, or relative to, rotary or oscillating bodies
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

two or more separators 2a are mounted for movement with rotary body 2b


Simultaneously, alternately, or selectively separating articles from two or more piles
Definition statement

This place covers:

Arrangements in which the piles from which to separate and the sequence in which to do so can be freely chosen

Illustrative example of subject matter classified in this group:


Special rules of classification

This main group should be used only for subject matter not being covered by any of its subgroups.

Supplementary devices or measures to assist separation or prevent double feed (control means comprising detectors responsive to double feed B65H 7/12)
Definition statement

This place covers:

Devices, e.g mechanical arrangements, or measures, e.g. procedures for driving the separator, which merely assist the separation, but which can not carry out a separation act on their own.

Relationships with other classification places

For control means comprising detectors responsive to double feed additionally classify in B65H 7/12.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Assisting separation or preventing double feed

B65H 2301/4234

Special rules of classification

This main-group should be used only for subject-matter not being covered by any of its sub-groups.

Air blast acting on edges of, or under, articles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Elements, e.g. fingers, plates, rollers, inserted or traversed between articles to be separated and remainder of the pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Non-driven retainers, e.g. movable retainers being moved by the motion of the article}
Definition statement

This place covers:

Arrangements which induce friction to articles by passive elements i.e. elements which are not driven by any power sources, neither externally nor internally with respect to the elements.

Illustrative example of subject matter classified in this group:


Special rules of classification

When the articles are standing on the edge (i.e. vertically stacked) the separation is done neither from the top nor from the bottom but from the side: This should be classified here.

{the retainers positioned under articles separated from the top of the pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Retainers of the pad-type, e.g. friction pads}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(see friction pad 50)


{the retainers positioned over articles separated from the bottom of the pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Retainers of the pad-type, e.g. friction pads}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(see friction pad 40)

{Driven retainers, i.e. the motion thereof being provided by a dedicated drive}
Definition statement

This place covers:

Arrangements which induce friction to articles by active elements i.e. elements which are driven by power sources either externally or internally with respect to the elements

Illustrative example of subject matter classified in this group:


Special rules of classification

When the articles are standing on the edge (i.e. vertically stacked) the separation is done neither from the top nor from the bottom but from the side: This should be classified here.

{the retainers positioned under articles separated from the top of the pile}
Special rules of classification

This group should be used only for subject-matter not being covered by any of its sub-groups.

{Retainers of the roller type, e.g. rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Retainers of the belt type, e.g. belts}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the retainers positioned over articles separated from the bottom of the pile}
Special rules of classification

This group should be used only for subject-matter not being covered by any of its sub-groups.

{Retainers of the roller type, e.g. rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Retainers of the belt type, e.g. belts}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Pressing or holding devices
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Elements, e.g. scrapers, fingers, needles, brushes, acting on separated article or on edge of the pile {(B65H 3/52 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(see retainers 5b)


References
Limiting references

This place does not cover:

Friction retainers acting on under or rear side of article being separated

B65H 3/52

Articles spiked, threaded, cemented, or gummed together, to prevent double feed, e.g. piles with gummed edges
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Loosening articles in piles
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



by swinging, agitating, or knocking the pile
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Assisting separation by vibration

B65H 2301/42342

by vacuum apparatus
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Article guides or smoothers, e.g. movable in operation
Definition statement

This place covers:

Arrangements which guide the article during separation i.e. when the article is not completely free from the pile jet.

Illustrative example of subject matter classified in this group:

Article guide 13 is movable during separation


Special rules of classification

For specifying details about article guides additionally classify in subgroups of B65H 2404/50, B65H 2404/60 and/or B65H 2404/70.

immovable in operation
Definition statement

This place covers:

Arrangements which guide the article during separation, i.e. when the article is not completely free from the pile jet.

Illustrative example of subject matter classified in this group:

(article guide 14)


Feeding articles separated from piles; Feeding articles to machines ({B65H 9/00 takes precedence; } identical mechanisms or parts for delivering or advancing articles from machines B65H 29/00; recirculating articles B65H 85/00 {, G03B 27/6257})
Definition statement

This place covers:

Arrangements for feeding articles separated from piles to machines, for example single or continuous streams of articles.

Relationships with other classification places

For arrangements concerning delivering or advancing articles from machines as well as to machines additionally classify in B65H 29/00 and subgroups.

Transferring material between transport devices additionally classify in B65H 2301/447 and subgroups combined with an B65H 2220/00 symbol (see B65H header).

References
Limiting references

This place does not cover:

Registering, e.g. orientating, articles; Devices therefor

B65H 9/00

Arrangements exclusively for delivering or advancing articles from machines

B65H 29/00

Recirculating articles

B65H 85/00

Special rules of classification

This main group should be used only for subject-matter not being covered by any of its sub-groups.

{Adaptations of counting devices (delivery of articles from machines B65H 29/001)}
Definition statement

This place covers:

Special arrangements related to article counting devices, such as banknote counting machines.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Adaptations of counting devices directed to feeding of articles from machine

B65H 29/001

{using electrostatic force}
Definition statement

This place covers:

Arrangements that use electrostatic forces (e.g. electro statically charged belts) to feed articles separated from piles. media108.png

{Feeding stacks of articles to machines}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

Handling piles, sets or stacks of articles additionally classify in B65H 2301/422 and subgroups.

{using vibrations}
Definition statement

This place covers:

Arrangements that use vibration forces (e.g. sound waves) to feed articles separated from piles.

by belts or chains {, e.g. between belts or chains (by combinations of endless conveyors and grippers B65H 5/085; by suction belts B65H 5/224)}
References
Limiting references

This place does not cover:

Arrangement which can be identified as either a belt or a chain.

Combinations of endless conveyors and grippers

B65H 5/085

Informative references

Attention is drawn to the following places, which may be of interest for search:

Printers

B41J 11/007

Copy machine (Handling original)

G03G 15/60

Copy machine (Handling copy sheet)

G03G 15/65

Handling banknotes

G07D 11/10

{by belts}
Definition statement

This place covers:

Arrangements using an endless belt wherein the transport force is created only by friction.


Relationships with other classification places

For details of construction and/or arrangement of belts additionally classify in subgroups of B65H 2404/20.

In particular, auxiliary handling means on the surface of the belts additionally classify in subgroups of B65H 2404/23.

References
Limiting references

This place does not cover:

Perforated belts in which suction is used to enhance adherence of the article on the belt

B65H 5/224

Belts for transporting sheets through electrographic units

G03G 15/65

{between a pair of belts forming a transport nip}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{between belts and rotary means, e.g. rollers, drums, cylinders or balls, forming a transport nip}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{between belts and stationary pressing, supporting or guiding elements forming a transport nip}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements of belts facing a transport surface, e.g. contact glass in copy machine

B65H 2404/268

{by chains}
Definition statement

This place covers:

Conveying means which consist of interlinked elements.


Relationships with other classification places

For details of construction and/or arrangement of chains additionally classify in B65H 2404/30 and subgroups.

by movable tables or carriages (rotary tables B65H 5/18 {; suction gripper or gripper tables B65H 5/10})
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Suction grippers or gripper tables

B65H 5/10

Rotary tables

B65H 5/18

by rollers {or balls, e.g. between rollers (transport by suction rollers B65H 5/226)}
Definition statement

This place covers:

Arrangements using rollers wherein the transport force is created only by friction.

References
Limiting references

This place does not cover:

Suction rollers

B65H 5/226

Special rules of classification

Special construction of feed or guide rollers and surfaces thereof should be classified in B65H 27/00 together with an additional symbol from B65H 2404/10 and subgroups.

{between rollers or balls}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the axes of the rollers being perpendicular to the plane of the articles}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the articles resting on rollers or balls}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{between one or more rollers or balls and stationary pressing, supporting or guiding elements}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

For specifying details about stationary pressing, supporting or guiding elements additionally classify in subgroups of B65H 2404/50 and/or B65H 2404/60.

by grippers, e.g. suction grippers
Definition statement

This place covers:

Arrangements using grippers to transport the article separated from the pile.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Grippers, e.g. suction or magnetic

B65G 17/323

Special rules of classification

This group should be used only for subject-matter not being covered by any of its sub-groups.

{by combinations of endless conveyors and grippers (suction belts B65H 5/224)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Grippers carried by chains or bands

B65H 2301/44712

General conveyors with grippers carried by endless conveyors

B65G 47/842

Reciprocating or oscillating grippers {, e.g. suction or gripper tables}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Revolving grippers, e.g. mounted on arms, frames or cylinders
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Reversing sheets inside printing machines, e.g. perfecting roller/machine

B41F 21/106

Details of grippers; Actuating-mechanisms therefor
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Manipulators with gripper heads

B25J 15/08

by pusher, needles, friction, or like devices adapted to feed single articles along a surface or table
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Auxiliary handling means on the surface of the belts

B65H 2404/23

by rotary dials or tables
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(top view)


by air-blast or suction device (suction grippers B65H 5/08)
References
Limiting references

This place does not cover:

Suction grippers

B65H 5/08

{by suction devices}
Special rules of classification

This group should be used only for subject-matter not being covered by any of its sub-groups.

{by suction belts (B65H 11/005 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Feed tables incorporating suctions belts

B65H 11/005

{by suction rollers}
Definition statement

This place covers:

Rollers wherein the suction is generated by a vacuum inside the roller.


{by air-blast devices}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Directly conveying articles by flowing gases

B65G 51/02

{Feeding articles in overlapping streams, i.e. by separation of articles from a pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

If the overlapping stream is not formed exclusively by separation of articles from a pile then this group and subgroups take precedence.

B65H 29/66

Informative references

Attention is drawn to the following places, which may be of interest for search:

Overlapped conveying (FTCLA)

3F053/GB00

Duplicate, alternate, selective, or coacting feeds
Definition statement

This place covers:

Arrangements in which more than one path or route of transport is selectable either to the same or to different destinations

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Combinations of piling and depiling operations from and o the same stack

B65H 83/02

Recirculating articles

B65H 85/00

Feeding articles stored in rolled or folded bands
Definition statement

This place covers:

Specific details or aspects concerning feeding the stored articles from the store.


Relationships with other classification places

For details about the winding and unwinding means additionally classify in subgroups of B65H 2301/419.

References
Limiting references

This place does not cover:

Particular details or aspects concerning feeding of articles to be stored in rolled or folded bands, as well as details about the storing arrangement as such

B65H 29/006

Informative references

Attention is drawn to the following places, which may be of interest for search:

Articles wound together with a single belt

B65H 2301/4191

Articles wound together between two belts facing each other

B65H 2301/41912

Note containers

G07D 11/12

Relevant UCLA

242/528

Opening devices for folded sheets or signatures
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

For opening signatures

B42B 9/02

Relevant UCLA

270/52.23, 270/52.24, 270/52.25

Special rules of classification

This group should be used only for subject-matter not being covered by any of its sub-groups.

{comprising blade-like means inserted between the parts to be opened}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the blade-like means being stationary}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{comprising movable endless means for opening the folded sheets (B65H 5/308 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Folded sheets or signatures travelling in hanging position

B65H 5/308

{comprising rotary means for opening the folded sheets (B65H 5/308 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(opening folded sheets 5)


References
Limiting references

This place does not cover:

Folded sheets or signatures travelling in hanging position

B65H 5/308

{two opposite rotary means, only one of them having gripping means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{two opposite rotary means, both having gripping means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(gripping means 54,56)


{the folded sheets or signatures travelling in hanging position}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Saddle-like members over which partially-unfolded sheets or signatures are fed to signature-gathering, stitching, or like machines
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Varying the phase of feed relative to the receiving machine
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

Specific control aspects should additionally be classified in subgroups of B65H 7/00.

Article guides or smoothers, e.g. movable in operation
Definition statement

This place covers:

Arrangements which guide the article during transport. The article is completely free from the pile.

Illustrative example of subject matter classified in this group:


Relationships with other classification places

For specifying details about article guides additionally classify in subgroups of B65H 2404/50, B65H 2404/60 and/or B65H 2404/70.

immovable in operation
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

(cf. guide plate 23)


References
Limiting references

This place does not cover:

For stationary guides or smoothers for delivering or advancing articles from machines

B65H 29/52

Controlling article feeding, separating, pile-advancing, or associated apparatus, to take account of incorrect feeding, absence of articles, or presence of faulty articles
Definition statement

This place covers:

Aspects related to controlling the handling of articles before they arrive to a particular process, such as pile-advancement, picking articles from piles, article feeding and separation, and apparatuses associated with such acts, to take account of incorrect feeding of articles, incorrect absence of articles, or presence of faulty articles

References
Limiting references

This place does not cover:

Aspects related to controlling the handling of articles after the articles have been subjected to a particular process. Such aspects are covered B65H 43/00

Special rules of classification

Because the sensing nowadays in the majority of cases is realized through photoelectric sensors, the majority of documents would have to be classified in B65H 7/14 if the IPC precedence notes were followed. In order to rationalize classification the IPC note "B65H 7/14 takes precedence" is ignored.

The rules followed are the following:

Documents are first classified according to which part of the article or to which situation the feelers or detectors respond. If the sensor works with an photoelectrical element and the structural build up of the sensor is particularly emphasized, then the document is classified in B65H 7/14 as well.

Additionally, codes from B65H 2511/00, B65H 2513/00, B65H 2515/00, B65H 2519/00, B65H 2551/00, B65H 2553/00, combined with at least the indicators B65H 2220/01, B65H 2220/02, B65H 2220/03, B65H 2220/04 should be given to further specify the control aspects.

The codes B65H 2511/00, B65H 2513/00, B65H 2515/00, B65H 2519/00, B65H 2551/00, B65H 2553/00, combined with indicators from the B65H 2220/00 series can be given without a symbol from the B65H 7/00 series if the control aspect is only a secondary aspect.

If the document disclose a device and/or method for controlling in which the reaction e.g. the control out put is emphasized, then the document should be further classified in one of the groups B65H 7/16, B65H 7/18, B65H 7/20.

Examples:

  • (I) A document disclosing a device and/or method for controlling responsive to double feed, and emphasizing the structure of the photoelectrical sensor which has elements which contact the articles while sensing, should be classified in: B65H 7/12 and B65H 7/14
  • If the elements which contact the articles are particularly specified (for example rotating levers), a further B65H symbol (B65H 2553/612: Contact arms, Levers, Antennas) should be given.
  • (II) A document disclosing a device and/or method for controlling responsive to double feed, and emphasizing the structure of the photoelectrical sensor which does not contact the actual articles while sensing, should be classified in: B65H 7/125 and B65H 7/14
  • (III) A document disclosing a device and/or method for controlling responsive to a wrong distance between articles successively separated from a pile of article, monitoring said distance by checking the time intervals (B65H 2513/53) between the passing of the front edges of the articles (B65H 2701/1311) (sensed by a light sensor not further specified), and responding by changing the rotational speed of the separator (B65H 2513/11), should be classified in:
  • If the change of the rotational speed of the separator, or means to do so are particularly emphasized, then the class B65H 7/18 should be given additionally.
  • (IV) A pile is advanced/moved in function of an absence of articles:
  • (V) The position of the separation end of the pile is controlled in function of the thickness of the articles:
by photoelectric feelers or detectors
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Instruments using optical measuring means

G01B 9/00

Measuring arrangements characterised by the use of optical means

G01B 11/00

Controlling associated apparatus
Definition statement

This place covers:

The group covers for example the concept that the handling conditions (for example the feeding speed) before a process influence or determine the conditions or settings of the process it self (for example the starting time).

The group also covers subject-matter which emphasizes the particular interface means applied or functioning between the handling action (for example feeding) and the process. Such interface means could be for example communication means between the feeding controller and process controller, or user interfaces like information input or displaying means linked to the feeding controller.

Special rules of classification

Interface means should be indicated by giving a code from B65H 2551/00 or B65H 2557/00

Registering, e.g. orientating, articles; Devices therefor
Definition statement

This place covers:

Aspects related to correcting the orientation and/or position of the articles before they arrive to a particular process.

References
Limiting references

This place does not cover:

Correcting orientation and/or position of articles when coming from a process

B65H 29/00, B65H 31/00

Combined with

B65H 2301/331, B65H 2301/361

Devices intimately associated with inserting documents into envelopes:

B43M 3/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Printer, registering devices

B41J 13/26

Printers, Front lays, stops, or gauges

B41J 13/28

Printers, Side lays or gauges

B41J 13/30

Printers, Means for positioning sheets in two directions under one control, e.g. for format control or orthogonal sheet positioning

B41J 13/32

Apparatus for electrographic processes, feeding path after the copy sheet separation and up to the transfer point, e.g. registering; deskewing; correct timing of sheet feeding to the transfer point

G03G 15/6558

Apparatus for electrographic processes, registration devices:

G03G 2215/00405

Aligning cards

G06K 13/063

{changing orientation of sheet by only controlling movement of the forwarding means, i.e. without the use of stop or register wall}
Definition statement

This place covers:

Arrangements which corrects the orientations of the sheets, i.e. deskews the sheets, only by controlling the relative speed of the forwarding means without abutting the edges of the sheets against stops or register walls

Illustrative example of subject matter classified in this group:


Special rules of classification

If the subject-matter also relates to an additional movement which moves the article in a second direction perpendicular to the first movement, this should be indicated by using the appropriate B65H symbol. For example, if the first change of orientation is done by counter rotating two independent roller pairs (B65H 9/002) and the second change of movement is done by moving the rollers parallel to their shafts, then the symbol B65H 2404/1424 should be given additionally, see for example US2009033029A1.

{Deskewing sheet by abutting against a stop, i.e. producing a buckling of the sheet}
Definition statement

This place covers:

The concept that the deskewing effect is caused by a significant buckling of the article


References
Limiting references

This place does not cover:

The article is moved into a stationary registered position, but not buckled

B65H 9/10

Special rules of classification

If a movable stop is important in connection with the buckling of the article then also classify in B65H 9/06

{the stop being formed by forwarding means in stand-by}
Definition statement

This place covers:


{the stop being formed by reversing the forwarding means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Fixed or adjustable stops or gauges (gauge pins B65H 9/02)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

Adjustable guides on supports which do not perform a registering or orientation action on an article but merely define a certain space for the stack according to the size should be classified as follows:

Adjustable in both length and width direction of the article by the operator:

Adjustable in width direction of the article by the operator:

Movable stops or gauges, e.g. rising and falling front stops {(B65H 11/007 takes precedence)}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:




References
Limiting references

This place does not cover:

Feed tables with front stop arrangements

B65H 11/007

Special rules of classification

If the stops produce a buckling of the articles specifically used for deskewing then also classify in B65H 9/004

Holding devices, e.g. finger, needle, suction, for retaining articles in registered position
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Pusher and like movable registers; Pusher or gripper devices which move articles into registered position
Definition statement

This place covers:

Means which moves the article into stationary registered positions. e.g. which move the article into a stationary position against a stop or register wall. The stop can be a physical stop or wall, but can also be a virtual stop, for example formed by an array of sensors.

References
Limiting references

This place does not cover:

Registering laterally against a side register while the article is forwarded in principal direction

B65H 9/16

Special rules of classification

After the notation of the groups B65H 9/10 - B65H 9/108 and separated therefrom by a + sign, the symbol B65H 2220/15 may be added to indicate that the device moves articles, already positioned in a stationary registered position according to a first direction, into a stationary registered position along a second direction perpendicular to the first one, e.g. for lateral registering, in other words, the registration action consists of two distinct successive movements with a stop in between, the movements being perpendicular to each other.

{acting on the edge of the article}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{acting by friction or suction on the article for pushing or pulling it into registered position, e.g. against a stop}
Definition statement

This place covers:

Acting by friction is typically done by applying friction pads (see EP1396452, pad (08)), but the group also covers the concept of pinching the article between stopped rollers and moving these parallel to their shaft (see US20040046313).



{using suction means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using rotary driven elements as part acting on the article (B65H 9/105 takes precedence; registering laterally while article is forwarded in principal direction B65H 9/16)}
Definition statement

This place covers:

"Using rotary driven elements" limits the coverage of this group to arrangements wherein the movement is provided by actually driven elements, like rotating rollers or belts (see US2001012465, rollers (141,143,151)).


References
Limiting references

This place does not cover:

A non rotating roller pair which is pinching the article and then being moved for pulling the article against a stop should be classified in

B65H 9/103

Rotating suction rollers

B65H 9/105

Registering laterally against a side register wall while the article is forwarded in principal direction

B65H 9/106

{acting by air blast}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


carried by article grippers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Retarding or controlling the forward movement of articles as they approach stops
Definition statement

This place covers:

Mechanical arrangements for controlling the forward movement of articles as they approach stops

Illustrative example of subject matter classified in this group:


Inclined tape, roller, or like article-forwarding side registers
Definition statement

This place covers:

Registering laterally against a side register while the article is forwarded in principal direction. i.e. no front stops, the forward motion continues.


References
Limiting references

This place does not cover:

Registering laterally against a side register while the article is forwarded in principal direction against a front register wall or stop

B65H 9/10

Feed tables
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:




{incorporating transport belts}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{with front stop arrangements}
Definition statement

This place covers:

See the stop elements (20) in illustrative example 1, elements (10,10') in illustrative example 2, and elements (69) in illustrative example 3 shown below:

Illustrative example 1:


Illustrative example 2:


Illustrative example 3:


Lifting the ends of piles to facilitate the formation of overlapped piles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Overturning articles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Star wheel type devices

B65H 29/40

If the overturning is a mere consequence of refeeding the article back to the work-station in order to process the other side

B65H 85/00

Overturning/reversing sheets inside rotary printing machines e.g. perfecting rollers/machines

B41F 21/106

Special rules of classification

To be classified together with relevant symbols from B65H 2301/332 - B65H 2301/3332, in particular B65H 2301/3321 - B65H 2301/33216 and B65H 2301/3322 - B65H 2301/33224.

Unwinding, paying-out webs {(reel-to-reel type web winding and unwinding mechanisms B65H 18/103, B65H 18/145)}
Definition statement

This place covers:

Unwinding mechanisms for a depleting the web continuously.

References
Limiting references

This place does not cover:

Devices or arrangements of selective printing mechanisms, e.g. ink-jet printers, thermal printers

B41J 1/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Uncoilers of wound sheet metal web material

B21C 47/00

Special rules of classification

For expandable mandrels, chucks, e.g. for securing or releasing cores, holders or packages add B65H 75/242

{Dispensers, i.e. machines for unwinding only parts of web roll}
References
Limiting references

This place does not cover:

For constructional details of cores, supports or holders for wound material

B65H 75/02

Toilet paper dispensers

A47K 10/32

Containers or packages with special means for dispensing contents

B65D 83/00

Supporting web roll
Definition statement

This place covers:

Support mechanisms for continuous unwinding systems.

References
Limiting references

This place does not cover:

Machines unwinding only parts of web roll, i.e. dispensers

B65H 16/005

Special rules of classification

For further aspects of supporting web roll, e.g. constructional details, B65H 2301/413 and lower.

{Multiple web roll supports}
Definition statement

This place covers:

Unwinding unit presenting multiple web roll supports on several web roll holders, e.g. separate magazines, or presenting multiple web roll supports on a single web roll holder, e.g. coaxially aligned web rolls;



Special rules of classification

For additional details of multiple web roll supports add B65H 2301/4139 or lower.

{rotatable}
Definition statement

This place covers:

The support or holder being rotatable

{on its outer circumference (B65H 16/08 takes precedence)}
Definition statement

This place covers:

Web supports in contact with web periphery.

References
Limiting references

This place does not cover:

Parallel rollers type

B65H 16/08

cantilever type
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

For additional details of cantilever supports see B65H 2301/4132 or lower.

both-ends type
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

For additional details of both-end supports B65H 2301/4134 or lower.

parallel rollers type
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for effecting positive rotation of web roll
Definition statement

This place covers:

Power mechanism used for the rotation of the web-roll.

Winding webs
Definition statement

This place covers:

Winding or rewinding of webs in a continuous process.

References
Limiting references

This place does not cover:

Winding mechanisms in combination with a change of web roll

B65H 19/00

Special rules of classification
  • For others aspects of web winding processes add B65H 2301/414 or lower;
  • For auxiliary processes performed during winding B65H 2301/50;
  • For winding in combination with measuring a length, e.g. inspecting devices, add B65H 2511/11;
  • For winding in combination with slitted webs, add systematically B65H 2301/4148;
Supporting web roll
Definition statement

This place covers:

Support arrangement for continuous winding units.

References
Limiting references

This place does not cover:

For winding support arrangements whereby the central support is removed after winding, e.g. a mandrel of a turret winder

B65H 19/2292

Special rules of classification

For details related to the core itself add B65H 75/02 and lower.

{Multiple web roll supports}
Special rules of classification

For slitter-rewinder in which winding takes place on two or more shafts add B65H 2301/41486.

For additional details of multiple web roll support add B65H 2301/4139 or lower.

{on its outer circumference}
Definition statement

This place covers:

Web supports in contact with web periphery.

{Parallel rollers type}
Definition statement

This place covers:

Parallel rollers supporting the web in a tangential or nip contact.

References
Limiting references

This place does not cover:

Parallel rollers with a web winding mechanism

B65H 18/20

{Cantilever type}
Special rules of classification

For additional details of cantilever supports see B65H 2301/4132 or lower.

{Both ends type}
Definition statement

This place covers:

Supports of both end type.


Special rules of classification

For additional details of both-end supports B65H 2301/4134 or lower.

Interior-supporting
Definition statement

This place covers:

Web supports with an axial connexion body holding the web.


Lateral-supporting
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Articulated bearing

F16D 1/0811

Web-winding mechanisms
References
Limiting references

This place does not cover:

Coreless winding systems

B65H 19/2276

Changing the web roll in winding systems whereby the core or mandrel is removed after winding

B65H 19/2292

Special rules of classification

For details about the type of power transmission or driving means used B65H 2403/00.

Mechanisms in which power is applied to web-roll spindle
References
Limiting references

This place does not cover:

Articulated bearing

F16D 1/0811

{Reel-to-reel type web winding and unwinding mechanisms}
Definition statement

This place covers:

Arrangement associating an unwinding mechanism and a winding mechanism whereby a source roll is unwinded while the depleted web is rewinded on a target roll, e.g. cassette apparatus

{for several juxtaposed strips}
Special rules of classification

For slitting and winding on two or more shafts simultaneously add B65H 2301/41486 or lower

to effect step-by-step advancement of web
Definition statement

This place covers:

Winding mechanism for a stepwise web advancement in intervals

Mechanisms in which power is applied to web roll, e.g. to effect continuous advancement of web
Definition statement

This place covers:

Winding mechanism applying a driving power by contact with a web roll surface, e.g. driving belt

{Reel-to-reel type web winding and unwinding mechanisms}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by friction roller
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

For step-by-step advancement mechanisms add B65H 2301/4493.

to effect step-by-step advancement of web {(not used)}
Definition statement

This place covers:

Winding mechanism for a stepwise web advancement in intervals.

the web roll being supported on two parallel rollers at least one of which is driven
Special rules of classification

For constructional details of a rider roll B65H 2404/43 and lower.

by friction band
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

For step-by-step advancement mechanisms add B65H 2301/4493.

Mechanisms for controlling contact pressure on winding-web package, e.g. for regulating the quantity of air between web layers
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

By means of indirect measurement or calculation

B65H 2511/142, B65H 2220/03

Special rules of classification

For constructional details of a rider roll add B65H 2404/43 or lower.

Wound package of webs
Definition statement

This place covers:

Properties of wound package of webs, e.g. bonding the outermost web trailing end to the web roll independently from a web roll change.

References
Limiting references

This place does not cover:

Starting a new winding cycle by attaching or wrapping the innermost leading end of the roll to the new core or mandrel

B65H 19/28

Finishing a winding cycle by bounding the outermost trailing end to the web roll

B65H 19/29

Special rules of classification

For properties of handled webs in wound packages add B65H 2701/184 or lower;

For properties of storage means, e.g. special core properties, add B65H 2701/50 or lower;

For blocking outer layers add B65H 2301/41441 or lower;

For web delivery apparatus incorporating devices for performing specified auxiliary operations add B65H 37/002 or lower

Changing the web roll
Definition statement

This place covers:

Winding or unwinding operations dealing with changing the web roll.

References
Limiting references

This place does not cover:

For web splicing operations not linked to a web roll change

B65H 21/00

{Opening of web rolls; Removing damaged outer layers; Detecting the leading end of a closed web roll}
Definition statement

This place covers:

Preliminary operations dealing with the external surface or leading edge of a wound web roll taking place before the unwinding starts.

Special rules of classification

For further details related to the opening of web rolls add B65H 2301/4604 or lower.

{with cantilever supporting arrangements}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

This arrangement provides two cantilever suppors (6,7) for two rolls (8,9)


{with both-ends supporting arrangements}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Accumulating surplus web for advancing to machine while changing the web roll
References
Limiting references

This place does not cover:

During a change of web roll and in connection with winding operations

B65H 19/24

With mechanisms for advancing webs from or to the inside of web rolls

B65H 20/26

In general, i.e. for accumulating surplus of web without a change of web roll

B65H 20/30

Devices for temporarily storing filamentary material during forwarding of filamentary material, e.g. for buffer storage

B65H 51/20

Easily-flexible work, e.g. wire, sheet metal bands

B21B 41/00

Manufacture of metal sheets, metal wire, metal rods, metal tubes by drawing

B21C 49/00

Attaching, e.g. pasting, the replacement web to the expiring web {(adhesive arrangements on leading end of replacement web, tabs and adhesive tapes for splicing B65H 19/102)}
Definition statement

This place covers:

Splicing of a replacement web with an expiring web.

References
Limiting references

This place does not cover:

Adhesive arrangements on leading end of replacement web, tabs and adhesive tapes for splicing

B65H 19/102

Special rules of classification

For additional features related to splicing processes B65H 2301/46 and to splicing machines or units B65H 2408/22.

{Flying splicing, i.e. the expiring web moving during splicing contact}
Definition statement

This place covers:

The operation of attachment is taking place on a moving expiring web.

{standing splicing, i.e. the expiring web being stationary during splicing contact}
Definition statement

This place covers:

The operation of attachment is taking place on a stationary expiring web.

Special rules of classification

For constructional details of accumulators add B65H 2408/21 or lower.

{Support arrangement of web rolls}
Definition statement

This place covers:

Specific web support arrangement used for splicing webs.

Cutting-off the expiring web
Definition statement

This place covers:

Details about cutting-off, i.e. separating, the expiring web in combination with a web roll change, including a splicing operation.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Cutting-off the tail of an expiring web after a splicing operation

B65H 2301/46152

Special rules of classification

For cutting expiring webs in combination with splicing operations add B65H 2301/4617 or lower.

{Turret-type with more than two roll supports}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{The web roll being driven by a winding mechanism of the nip or tangential drive type (B65H 19/2276 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

The web roll being driven by a winding mechanism of the coreless type

B65H 19/2276

{and the roll being supported on two rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{and the roll being displaced during the winding operation}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Pope-roller}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Cradle}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{The web roll being driven by a winding mechanism of the coreless type}
Definition statement

This place covers:

Winding without pre-formed cores, i.e. without a core (coreless) or a core being formed with the winding process (in-line core winding), e.g. winding of logs.


Special rules of classification

For winding a core in-line with the web (wound core made out of sheet material) add B65H 2301/414325.

For further details on core or mandrel discharge or removal add B65H 2301/4185 or lower.

{Simultaneous winding at several stations, e.g. slitter-rewinders}
Definition statement

This place covers:

  • Aspects related to the change of web roll in combination with the simultaneous winding at several stations, e.g. web roll discharge or transport at the end of winding in a slitter-winder.
  • The simultaneous winding at several stations, e.g. slitter-rewinders


References
Limiting references

This place does not cover:

Aspects exclusively related to the rewinding process after slitting

B65H18/25

Informative references

Attention is drawn to the following places, which may be of interest for search:

Slitting

B65H 2301/4148

Winder slitter

B26D 2007/0075 ( B26D)

{Removing cores or mandrels from web roll after winding}
Definition statement

This place covers:

Attaching and winding the web around a support element before removing it axially after winding; the roll remaining without any central element,

e.g. removing a mandrel after a coreless winding or removing a mandrel and a core after winding with a core.

References
Limiting references

This place does not cover:

For expansible mandrels

B65H 75/242

Informative references

Attention is drawn to the following places, which may be of interest for search:

Roll support type, e.g. cradle, turret or bed-winder

B65H 18/00, B65H 19/00

Removing roll/core from shaft/mandrel, e.g. by compressed air

B65H 2301/41446

Special rules of classification

For further details on core or mandrel discharge or removal add B65H 2301/4185 and lower.

This class does not include winding of rolls whereby a core remains after winding, e.g. turret winder with cores

Accumulating surplus delivered web while changing the web roll
References
Limiting references

This place does not cover:

During a change of web roll and in connection with unwinding operations

B65H 19/14

With mechanisms for advancing webs from or to the inside of web rolls

B65H 20/26

In general

B65H 20/30

Devices for temporarily storing filamentary material during forwarding, e.g. for buffer storage

B65H 51/20

Easily-flexible work, e.g. wire, sheet metal bands

B21B 41/00

Manufacture of metal sheets, metal wire, metal rods, metal tubes by drawing

B21C 49/00

Cutting-off the web running to the wound web roll
Definition statement

This place covers:

Separating the web running to the wound web roll to finish the winding of the active roll and transfer the web to the next empty core

{using a thin or filamentary material which is wound on the new roll}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

Web changing operations using a thin or filamentary material as tearing element, e.g. a double adhesive tape to tear-off the running web and to guide the leading end of the new web on a new core.


{using a cutting member moving linearly in a plane parallel to the surface of the web and along a direction crossing the web}
Definition statement

This place covers:

A cutting process whereby a mechanical cutting element is penetrating the web and cutting the web by moving the cutting element linearly in a plane parallel to the surface of the web and along a direction crossing the web

Illustrative example of subject matter classified in this group:


{by tearing or bursting}
Definition statement

This place covers:

I.e. any cutting process on a running web that is not using a mechanical cutting element penetrating the web in order to tear or burst the web, it includes e.g. tearing against a fixed edge, tearing by longitudinal forces, air or water cutting e.g. a jet of compressed air


Attaching the leading end of the web to the replacement web-roll core or spindle (cores, formers, supports or holders, e.g. reels, with arrangements for securing ends of material B65H 75/28)
References
Limiting references

This place does not cover:

Cores, formers, supports or holders, e.g. reels, with arrangements for securing ends of material

B65H 75/28

Informative references

Attention is drawn to the following places, which may be of interest for search:

Further splicing details

B65H 2301/46

Preparing leading edge for splicing

B65H 2301/4606

The kind of splicing means used, e.g. glue,

B65H 2301/463

Securing the trailing end of the wound web to the web roll (cores, formers, supports or holders, e.g. reels, with arrangements for securing ends of material B65H 75/28)
Special rules of classification

For further aspects see additionally B65H 2301/41441 or lower.

Lifting, transporting, or removing the web roll; Inserting core
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

For finishing the winding process in combination with blocking the outer layers

B65H 2301/41441

For further actions taking place after winding process

B65H 2301/41445

{Inserting core}
References
Limiting references

This place does not cover:

For filamentary materials B65H 67/0405 and lower.

Advancing webs
Definition statement

This place covers:

Constructional aspects of driving systems for the advancement of webs and units dealing with the advancement of webs, e.g. temporary storage of webs in accumulators.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

By advancing mechanisms using web-gripping means

B65H 20/16

Manufacture of metal sheets, i.e. profiles or tubes B21C, e.g. feeding or guiding devices in winding-up, coiling or winding-off devices

B21C 47/34

Devices for temporarily accumulating material

B21C 49/00

Working or processing of sheet metal or metal tube B21D: e.g. advancing work by means of one or more of pairs of rollers for feeding sheet or strip material

B21D 43/09

Shaping or joining of plastics, shaping of substances in a plastic state: e.g. of plates or sheets

B29C 55/02

Printing machines or presses: for conveying or guiding webs through, e.g. threading,

B41F 13/02

Packaging articles or materials B65B: e.g. feeding webs from rolls by grippers

B65B 41/14

Calenders or accessories for paper-making machines: devices for threading a web tail

D21G 9/0063

Apparatus for electrographic processes which relate to the handling of copy material

G03G 15/65

Mechanisms for advancing webs to or from the inside of web rolls
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Accumulating surplus web for advancing to machine while changing the web roll in unwinding mechanisms or in connection with unwinding operations

B65H 19/14

Accumulating surplus delivered web while changing the web roll in winding mechanisms or in connection with winding operations

B65H 19/24

Advancing webs, arrangements for accumulating surplus web

B65H 20/30

Devices for temporarily storing filamentary material during forwarding

B65H 51/20

Guiding, conveying, or accumulating easily-flexible work

B21B 41/00

Devices for temporarily accumulating material

B21C 49/00

Special rules of classification

See for coil type accumulator in FICLA B65H 19/14 or B65H 20/30.

Arrangements for accumulating surplus web (while changing the web roll B65H 19/14, B65H 19/24)
References
Limiting references

This place does not cover:

During a change of web roll and in connection with unwinding operation

B65H 19/14

During a change of web roll and in connection with winding operations

B65H 19/24

With mechanisms for advancing webs from or to the inside of web rolls

B65H 20/26

Devices for temporarily storing filamentary material during forwarding, e.g. for buffer storage

B65H 51/20

For easily-flexible work, e.g. wire, sheet metal bands

B21B 41/00

For manufacture of metal sheets, metal wire, metal rods, metal tubes by drawing

B21C 49/00

Special rules of classification

(04-97) see for coil type accumulator in FICLA B65H 19/14 or B65H 20/30.

by making loops
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with rollers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


having means to optionally advance the web either in one longitudinal direction or in the opposite longitudinal direction
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Bidirectional powered handling device

B65H 2403/942

Apparatus for splicing webs (during web-roll changing B65H 19/00)
References
Limiting references

This place does not cover:

When the splicing takes place during web-roll change

B65H 19/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Further splicing aspects

B65H 2301/46

for premarked, e.g. preprinted, webs
Definition statement

This place covers:

Splicing units whereby a mark or print on the web triggers the splicing operations.

Warning or safety devices, e.g. automatic fault detectors, stop-motions, for web-advancing mechanisms (safety devices in general F16P; investigating chemical or physical properties of materials in general G01N; indicating devices in general G08B)
Definition statement

This place covers:

Warning or safety devices, e.g. sensors, triggering an action or a signal.

References
Limiting references

This place does not cover:

For safety devices in general

F16P 1/00 - F16P 7/00

For signalling or calling systems, order telegraphs, alarm systems

G08B 1/00 - G08B 31/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

For indicating, counting, warning, control, or safety device in printing machine or presses

B41F 33/00

By the use of optical means, i.e. using infra-red, visible, or ultra-violet light

G01N 21/00

By specific methods not covered by the preceding groups

G01N 33/00

responsive to presence of irregularities in running webs
Definition statement

This place covers:

Detecting systems inspecting irregularities in running webs, e.g. faults.

{responsive to web breakage}
Definition statement

This place covers:

Detecting systems responsive to web breakage, e.g. detecting the positions of periodically recurring patterns, tension control systems.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

For web breakage in printing machines or presses

B41F 33/18

for variation in tension
Definition statement

This place covers:

Detecting systems responsive to variations in tension, e.g. tension measuring rolls.

responsive to predetermined lengths of webs
Definition statement

This place covers:

Signal or action triggered by a predetermined length of web.

responsive to a predetermined diameter
Definition statement

This place covers:

Signal or action triggered by a predetermined diameter.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

By means of indirect measurement or calculation

B65H 2511/142, B65H 2220/03

Special constructions of feed or guide rollers and surfaces thereof ({tentering rollers B65H 23/02} ; rollers in general F16C 13/00)
Definition statement

This place covers:

Construction aspects of feed or guide rollers and surfaces thereof, e.g. characterized by materials, surface structure, driving means,

use of fluid, roller pair construction.

References
Limiting references

This place does not cover:

Rollers in general

F16C 13/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Metal sheets or profiles: e.g. winding-up, coiling, winding-off several parallel metal bands

B21C 47/006

Feeding or guiding devices

B21C 47/34

Printing machines or rotary presses conveying or guiding webs

B41F 13/02

Printing machines or rotary presses cylinders

B41F 13/08

Typewriters, selective printing mechanisms (e.g. ink-jet printer, thermal printer)

B41J 13/02

Transport or storage device, e.g. conveyors for loading or tipping, shop conveyors, pneumatic tube conveyors

B65G 39/02

Treating textile materials by liquids, gases, vapours characterized by the use of fluid:

D06B 23/02

Textile fabrics: e.g. rollers for stretching, tentering or spreading textile fabrics

D06C 3/06

Rollers for calendering, pressing, ironing, glossing or glazing textile fabrics

D06C 15/08

Paper-making machine: e.g. guiding rolls in wet end of machines

D21F 1/40

Pressure rollers in press section (wet presses)

D21F 3/08

In calenders and accessories for paper-making machines: controlled deflection rolls with compensation means using fluid pressure

D21G 1/022

Apparatus for electrographic processes which relate to the handling of copy material

G03G 15/65

Special rules of classification

For further details concerning, e.g.

Materials used and their properties B65H 2401/00;

Roller(s) B65H 2404/10;

Shaft, cylinders, drums, spindles B65H 2404/40;

Surface of the elements in contact with the material forwarded or guided B65H 2404/50;

Means using fluid B65H 2406/00

Delivering or advancing articles from machines; Advancing articles to or into piles
Special rules of classification

This main group should be used only for subject matter (i.e. delivering or advancing articles from machines, advancing articles to or into piles) not being covered by any of its subgroups.media615.png

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Belt

band, tape.

Chain

a row of article handling elements, each interlinked with the adjacent one.

{Adaptations of counting devices (to feeding of articles to machines B65H 5/002)}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Adaptations of counting devices directed to feeding of articles to machine:

B65H 5/002

{by grippers (B65H 29/02 takes precedence)}
Definition statement

This place covers:

Delivering or advancing articles from machines, to piles or into piles by grippers engaging the articles at least somewhere else than at their leading edge, or somewhere that cannot be considered to be their leading edge, e.g. at the articles side, i.e. lateral edge, or e.g. at the hanging articles upper edge, or e.g. at the standing articles lower edge, or e.g. at the articles center or trailing edge.

Illustrative example of subject matter classified in this group:



References
Limiting references

This place does not cover:

by chains or bands having mechanical grippers engaging the side edges of articles

B65H 29/02

{by chains or bands having mechanical grippers engaging the side edges of articles, e.g. newspaper conveyors}
Definition statement

This place covers:

Delivering or advancing articles from machines, to piles or into piles by chains or bands carrying mechanical grippers engaging (relative to the conveying direction) the side edges of the articles.

Illustrative example of subject matter classified in this group:media618.png

{Winding articles into rolls}
Definition statement

This place covers:

Particular details about delivering articles to be stored to or into the store, as well as about the store as such.

Illustrative example of subject matter classified in this group:media619.png

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Feeding articles from rolls

B65H 5/28

Piling by collecting, e.g. piling, on the periphery of a cylinder

B65H 29/51

Wrapping banknotes around drum

G07D 9/00, 405C/FI

Reels taking-up banknotes

G07D 9/00, 405C/FI

Special rules of classification

Particular details or aspects about feeding the stored articles from the store: B65H 5/28

The use of the following Indexing Codes is mandatory:

B65H 2301/4191: articles wound together with a single belt

B65H 2301/41912: articles wound together between two belts facing each other

{Winding single articles into single rolls}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media620.png

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Sheet holders, retainers, movable guides, or stationary guides: for the sheet output section

B41J 13/106/EC

Piling by warping sheet

3F054/BA13/FT

Storage of roll-like sheet

3F054/BA15/FT

by mechanical grippers engaging the leading edge only of the articles
Definition statement

This place covers:

Delivering or advancing articles from machines, to piles or into piles by mechanical grippers engaging (relative to the conveying direction) the leading edge only of the articles.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles from machines, to piles or intopiles by grippers engaging the articles at least somewehere that relative to the conveying direction cannot be considered to be the leading edge

B65H 29/003

Special rules of classification

This group should be used only for subject matter (i.e.delivering or advancing articles from machines, to piles or into piles by mechanical grippers engaging relative to the conveying direction the leading edge only of the articles) not being covered by any of its lower subgroups.

the grippers being carried by endless chains or bands
Special rules of classification

This group should be used only for subject matter (i.e.delivering or advancing articles from machines, to piles or into piles by mechanical grippers engaging relative to the conveying direction the leading edge only of the articles, wherein the grippers are carried by endless chains or bands) not being covered by any of its lower subgroups.

{and introducing into a pile (slowing-down from grippers B65H 29/683)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media621.png

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Slowing down from (gripper) chain delivery

B65H 29/683

{Intermediate conveyors, e.g. transferring devices}
Definition statement

This place covers:

Advancing articles between handling or process stations of a machine, by mechanical grippers being carried by endless chains or bands, and engaging (relative to the conveying direction) the leading edge only of the articles.

{conveying through a machine}
Definition statement

This place covers:

Advancing articles through (a) handling or process station(s) of a machine,by mechanical grippers being carried by endless chains or bands, andengaging (relative to the conveying direction) the leading edge only of the articles.

Illustrative example of subject matter classified in this group:media622.png

{Details of grippers}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Feeding articles separated from piles or feeding articles to machines, by grippers

B65H 5/14

the grippers being carried by rotating members
Definition statement

This place covers:

Delivering or advancing articles from machines, to piles or into piles by grippers being carried by rotating members, e.g. arms or cylinders.

Illustrative example of subject matter classified in this group:



References
Limiting references

This place does not cover:

Transfer drums comprising grippers

B41F 21/10

Special rules of classification

Feeding articles separated from piles or feeding articles to machines, by grippers: B65H 5/14

the grippers being oscillated in arcuate paths
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

Feeding articles separated from piles or feeding articles to machines, by grippers

B65H 5/14

the grippers being reciprocated in rectilinear paths
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

Feeding articles separated from piles or feeding articles to machines, by grippers, details thereof: B65H 5/14

by means of the nip between two, or between two sets of, moving tapes or bands {or rollers}
Definition statement

This place covers:

Delivering or advancing articles from machines, to piles or into piles,by means of the nip between two, or between two sets of, moving tapes or bands or rollers.

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

sandwiching with belt and belt

3F049/DA02/Ft .

sandwiching by belt and roller

3F049/DA04/Ft

by oscillating conveyors

B65H29/60&E/FI

by moving a portion of belt

B65H29/60&H/FI

Special rules of classification

This group should be used only for subject-matter (i.e.delivering or advancing articles from machines, to piles or into piles,by means of the nip between two, or between two sets of, moving tapes or bands or rollers) not being covered by any of its lower sub-groups.

{between two sets of rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Sandwiching by roller and roller

3F049/DA12

and introducing into a pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{the pile being formed between the two, or between the two sets of, tapes or bands or rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by contact of one face only with moving tapes, bands, or chains {(with suction belts B65H 29/242)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles from machines, to piles or into piles, by means of suction belts

B65H 29/242

and introducing into a pile
Definition statement

This place covers:

example: introduncing articles into a pile from above the pile, see US4432685A


example: introducing articles into a pile from below the pile


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles into piles by suction bands or belts

B65H 29/242

Advancing the articles to or into piles by dropping the articles from tapes or bands rolled from under the articles

B65H 29/36

by contact with rotating friction members, e.g. rollers, brushes, or cylinders {(with suction rollers B65H 29/243)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles from machines, to or into piles by suction rollers

B65H 29/243

and introducing into a pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles into piles by suction rollers

B65H 29/243

Advancing the articles to or into piles by dropping the articles from rollers rolled from under the articles

B65H 29/36

by air blast or suction apparatus ({B65H 5/22 takes precedence; } dropping articles from suction carriers B65H 29/32 {; pneumatic brakes B65H 29/686})
References
Limiting references

This place does not cover:

Delivering or advancing articles from machines by contact with rotating friction members and introducing into a pile

B65H 5/22

Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles from machines, to piles or into piles, by dropping the articles from pneumatic, e.g. suction, carriers

B65H 29/32

Pneumatic brakes

B65H 29/686

Special rules of classification

This group should be used only for subject-matter (i.e. delivering or advancing articles from machines, to piles or into piles, by air blast or suction apparatus) not being covered by any of its lower sub-groups.

{Suction devices}
Special rules of classification

This group should be used only for subject-matter (i.e.delivering or advancing articles from machines, to piles or into piles, by suction devices) not being covered by any of its lower sub-groups.

{Suction bands or belts}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Suction rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Air blast devices}
Special rules of classification

This group should be used only for subject-matter (i.e.delivering or advancing articles from machines, to piles or into piles,by air blast devices)not being covered by any of its lower sub-groups.

{with coanda effect (separating from a stack B65H 3/14)}
References
Limiting references

This place does not cover:

Separating articles from piles using partial blasts producing partial vacuum

B65H 3/14

by dropping {the articles}
Definition statement

This place covers:

Delivering or advancing articles from machines, to piles or into piles,by dropping the articles.

Special rules of classification

This group should be used only for subject-matter (i.e.delivering or advancing articles from machines, to piles or into piles, by dropping the articles)not being covered by any of its lower sub-groups.

from mechanical grippers (grippers engaging the leading edge only B65H 29/02)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering or advancing articles from machines, to piles or into piles by grippers engaging an edge of the articles that relative to the conveying direction can not be considered to be the leading edge, e.g. rail guided gripping means, like so called "gripper chains" or "greiferketten", i.e. endless chains or bands carrying mechanical grippers engaging e.g. the upper edge of at least partially hanging articles, or the lowest edge of standing articles

B65H 29/003

Delivering or advancing articles from machines, to piles or into piles,by mechanical grippers engaging the leading edge only of the articles

B65H 29/02

from magnetic holders
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


from supports slid from under the articles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


from tapes, bands, or rollers rolled from under the articles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by movable piling or advancing arms, frames, plates, or like members with which the articles are maintained in face contact
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

This group should be used only for subject-matter (i.e.delivering or advancing articles from machines, to piles or into piles,by movable piling or advancing arms, frames, plates or like members with which the articles are maintained in face contact)not being covered by any of its lower sub-groups.

Members rotated about an axis perpendicular to direction of article movement, e.g. star-wheels formed by S-shaped members
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Members rotated about an axis parallel to direction of article movement, e.g. helices
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Members reciprocated in rectilinear path
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by tables arranged to be tilted to cause sliding of articles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Piling apparatus of which the discharge point moves in accordance with the height to the pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



piling by collecting on the periphery of cylinders
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

rotary folders

B65H 45/16

moving, guiding handled material by means in contact with opposite faces of handled material

B65H442/00, B65H344/00

storing banknotes

G07D 11/12

Stationary guides or smoothers
Definition statement

This place covers:


Article strippers, e.g. for stripping from advancing elements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


for stripping from elements or machines {(for electrographic machines G03G)}
Definition statement

This place covers:

Article strippers for removing from elements or machines, e.g. removing sheets from printing cylinders.

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Removing a copy sheet from a xerographic drum, band or plate

G03G15/00G4

Article switches or diverters
Definition statement

This place covers:

Constructional details of article switches or diverters, e.g. shape, material, actuation means.

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Duplicate, alternate, selective or coacting feeds

B65H 5/26:

Diverting sheets at a section where at least two sheet conveying paths converge, e.g. by a movable switching guide that blocks access to one conveying path and guides the sheet to another path, e.g. when a sheet conveying direction is reversed after printing on the front of the sheet has been finished and the sheet is guided to a sheet turning path for printing on the back]

B41J 13/009

{taking samples from the main stream}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


diverting the stream into alternative paths (B65H 29/62 takes precedence)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


This sub-group also covers particularties of paths, like paths arrangement or coordination, in terms of switching or diverting a stream of articles. media656.jpg

References
Limiting references

This place does not cover:

diverting faulty articles from the main streams (control devices detecting faulty articles

B65H 29/62

Informative references

Attention is drawn to the following places, which may be of interest for search:

Construcional details per se of article switches or diverters

B65H 29/58

diverting faulty articles from the main streams (control devices detecting faulty articles B65H 43/04)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Use of control, checking, or safety devices, e.g. automatic devices comprising an element for sensing a variable, namely detecting, or responding to, presence of faulty articles

B65H 43/04

directing the components of composite articles into separate paths
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Advancing articles in overlapping streams
Definition statement

This place covers:

Advancing articles in shingled formation.

Illustrative example of subject matter classified in this group:


Special rules of classification

This main-group should be used only for subject-matter (i.e. advancing articles in overlapping streams) not being covered by any of its lower sub-groups.

{forming an overlapping stream (by separation of articles from a pile B65H 5/24)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

by separation of articles from a pile

B65H 5/24

{upon transfer from a first conveyor to a second conveyor advancing at slower speed}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

This group should be used only for subject-matter (i.e. forming an overlapping stream upon transfer from a first conveyor to a second conveyor advancing at slower speed) not being covered by any of its lower sub-groups.

{in combination with auxiliary means for overlapping articles}
Definition statement

This place covers:

Auxiliary means facilitating the formation of a proper overlap between two articles.

Illustrative example of subject matter classified in this group:



{in combination with auxiliary means for underlapping articles}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{buffering an overlapping stream of articles (winding articles into rolls B65H 29/006)}
Definition statement

This place covers:

Buffering of a stream of articles in shingled formation, e.g. for compensating a downstream speed reduction.

Illustrative example of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Widing articles, e.g. in shingled formation, into rolls

B65H 29/006

{changing the overlapping figure}
Definition statement

This place covers:

Changing the overlapping figure, e.g. changing the amount of overlap.

Illustrative example of subject matter classified in this group:


{reversing the overlapping figure (round stack feeder B65H 1/225)}
Definition statement

This place covers:

Reversing the overlapping figure from overlapping figure to underlapping figure, or viceversa.

Illustrative example of subject matter classified in this group:



References
Limiting references

This place does not cover:

Round stack feeders

B65H 1/225

{dividing an overlapping stream into two or more streams; (articles switches or diverters B65H 29/58)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Constructional details of article switches or diverters

B65H 29/58

{merging two or more streams into an overlapping stream}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{ending an overlapping stream}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Reducing the speed of articles as they advance
Definition statement

This place covers:

Arrangements for reducing the speed of articles as they advance.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Deceleration

3F053/GA00/Ft

Special rules of classification

This main-group should be used only for subject-matter (i.e. reducing the speed of articles as they advance) not being covered by any of its lower sub-groups.

{Slowing-down from chain delivery (B65H 29/686 takes precedence)}
Definition statement

This place covers:

In particular arrangements for decelerating sheets in a "Bogenausleger" of a rotary printing machine, just before their piling.

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Reducing the speed of articles as they advance

B65H 29/686

{Pneumatic brakes}
Definition statement

This place covers:

Pneumatic means for reducing the speed of articles as they advance, e.g. suction rollers or belts making friction contact with the face of sheets, thus decelerating them from chain delivery just before being piled at a "Bogenausleger" of a rotary printing machine.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

(Deceleration) utilising suction force by air

3F053/GA07/FT

Suction belts, chains

3F053/GA08/FT

Suction rollers, pulleys

3F053/GA09/FT

Suction plates

3F053/GA10/FT

Article bending or stiffening arrangements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Pile receivers (carriers used for associating, collating or gathering articles B65H 39/00)
Definition statement

This place covers:

Pile receivers.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Pile receivers intimately associated with supports or magazines for piles from which articles are to be separated

B65H 1/00

Carriers used for associating, collating, or gathering articles

B65H 39/00

Combinations of piling and depiling operations, of interest apart from the single operation of piling or depiling

B65H 83/00

Special rules of classification

This main-group should be used only for pile receivers not being covered by any of its lower sub-groups.


Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Belt

band, tape

Chain

a row of article handling elements, each interlinked with the adjacent one

with stationary end support against which pile accumulates
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



with movable end support arranged to recede as pile accumulates
Definition statement

This place covers:

Pile receiver with movable end support arranged to recede as pile accumulates, the articles being piled e.g. in shingled formation.

Special rules of classification

This group should be used only for subject-matter (i.e. pile receivers with movable end support arranged to recede as pile accumulates) not being covered by any of its lower sub-groups.

the articles being piled on edge
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


and applied at the top of the pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Devices relieving the weight of the pile or permitting or effecting movement of the pile end support during piling
Special rules of classification

This group should be used only for subject-matter (i.e. devices relieving the weight of the pile or permitting or effecting movement of the pile end support during piling) not being covered by any of its lower sub-groups.

Springs (fluid springs B65H 31/16)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

Springs, e.g. mechanical springs. media681.png

References
Limiting references

This place does not cover:

Fluid pressure devices, e.g. fluid springs

B65H 31/16

Fluid-pressure devices
Definition statement

This place covers:

Fluid-pressure devices, like fluid springs.

Positively-acting mechanical devices
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


removable or interchangeable
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


multiple or compartmented, e.d. for alternate, programmed, or selective filling
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Forming counted batches by diverting batches to separate receivers:

B65H 33/14

Forming counted batches by depositing articles in batches on moving supports:

B65H 33/16

Pile receiver: Forming counted batches Multiple receivers

3F054/BF00/FT, 3F107/CD+

Auxiliary devices for retaining articles in the pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Maintaining pile , preventing collapse of cargo piles

3F054/BG00/FT

Bands, chains, or like moving receivers (for articles piled on edge B65H 31/06)
Definition statement

This place covers:

Pile receivers being conveying bands, chains or the like, that move during piling in order to enable the piling of articles thereon.

Illustrative example of subject matter classified in this group:



References
Limiting references

This place does not cover:

Delivering or advancing articles from machines; Advancing articles to or into piles by means of the nip between two, or between two sets of, moving tapes or bands the pile being formed between the two, or between the two sets of, tapes or bands or rollers]

B65H 29/145

Delivering or advancing articles from machines; Advancing articles to or into piles by contact of one face only with moving tapes, bands, or chains and introducing into a pile

B65H 29/18

Pile receivers with movable end support arranged to recede as pile accumulates the articles being piled on edge

B65H 31/06

Informative references

Attention is drawn to the following places, which may be of interest for search:

Delivering, advancing completed piles by moving a belt supporting the lowermost article of the pile:

B65H 31/3054

Forming counted batches in stream of articles by depositing articles in batches on moving supports:

B65H 33/16

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Chain

a row of article handling elements, each interlinked with the adjacent one.

Arrangements for removing completed piles (bands, chains, or like moving receivers B65H 31/28)
Definition statement

This place covers:

Arrangements for delivering, advancing completed piles.

Special rules of classification

This main-group should be used only for arrangements for delivering or advancing completed piles not being covered by any of its lower sub-groups.

{from opposite part-support elements, e.g. operated simultaneously}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

media687.jpgExample, side view

{by the nip between moving belts or rollers (pile being formed between belts or rollers B65H 29/145)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Introducing articles into piles, by means of the nip between two, or between two sets of, moving tapes or bands, the pile being formed between the two, or between the two sets of, tapes or bands:

B65H 29/145

{by gripping the pile}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Overturning piles:

B65H 15/02

Stacker cranes:

B65G 1/0407

{on the outermost articles of the pile for clamping the pile}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by moving the surface supporting the lowermost article of the pile, e.g. by using belts or rollers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

NL287910A


{by special supports like carriages, containers, trays, compartments, plates or bars, e.g. moved in a closed loop}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



{by acting on edge of the pile for moving it along a surface, e.g. by pushing}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Auxiliary devices for receiving articles during removal of a completed pile
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:

Auxiliary device = element with reference sign 304


Apparatus for squaring-up piled articles
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Matching

3F054/BH00/FT

Registration of pile

3F343/HE+/FT

Special rules of classification

This main-group should be used only for subject-matter (i.e. apparatus for squaring-up piled articles) not being covered by any of its lower sub-groups

Auxiliary devices for contacting each article with a front stop as it is piled
Definition statement

This place covers:

Auxiliary devices for contacting each article with a front stop as it is piled, typically arrangements bringing each article as it is piled into registration against stopping means.

Illustrative example of subject matter classified in this group:


Apparatus for vibrating or knocking the pile during piling
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

low vibrating articles

3f054/bh11/Ft

Separate receivers, troughs, and like apparatus for knocking-up completed piles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Forming counted batches in delivery pile or stream of articles
Definition statement

This place covers:

Forming counted batches of a determined number of articles in delivery pile or stream of articles.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Combinations of piling and depiling operations, of interest apart from the single operation of piling or depiling

B65H 83/00

Forming of counted batches (FTCLA)

3F107/FT

Special rules of classification

This main-group should be used only for subject-matter (i.e. forming counted batches in delivery pile or stream of articles) not being covered by any of its lower sub-groups.

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Batch

Typically an articles pile, or certain determined articles of a group

by inserting marker slips in pile or stream
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Placing job divider sheet between sets of sheets

G03G 15/655

Placing job divider sheet

G03G 2215/00894

Insertion of dividing members

3F107/CA+ (Japanese)

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Marker slip

Identification means to delimit a batch

by displacing articles to define batches
Special rules of classification

This group should be used only for subject-matter (i.e. forming counted batches in delivery pile or stream of articles by displacing articles to define batches) not being covered by any of its lower sub-groups.

Displacing whole batches, e.g. forming stepped piles
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Displacing the end articles of a batch
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by creating gaps in the stream
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Creating gaps in the stream

3F107/CC+ (Japanese)

by diverting batches to separate receivers {(B65H 33/16 takes precedence; article switches or diverters B65H 29/58)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Forming counted batches in delivery pile or stream of articles by depositing articles in batches on moving supports

B65H 33/16

Informative references

Attention is drawn to the following places, which may be of interest for search:

Constructional details of article switches or diverters

B65H 29/58

by depositing articles in batches on moving supports
Definition statement

This place covers:

Forming counted batches in stream of articles by depositing articles in batches on moving supports.


Special rules of classification

If batches are piles: for nature of supports, or for removing batches from their supports, see B65H 31/30 and lower.

with separators between adjacent batches
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Pile receiver; multiple receivers (FTCLA)

3F054/BF00

Forming counted batches; multiple receivers (FTCLA)

3F107/CD+

Delivering articles from cutting or line-perforating machines; Article or web delivery apparatus incorporating cutting or line-perforating devices, e.g. of the kinds specified below (cutting or perforating machines or devices in general B26D, B26F)
References
Limiting references

This place does not cover:

Severing by means other than cutting; Tearing per se

B26F 3/00; B26F 3/02

Feeding of wrapping material

B65B 41/00

Dispensing single sheets from a stack held together with temporary adhesive

B65D 83/08, B65C 11/00, B42D 5/003

Placing of tape onto a semi-conductor or wafer

H01L 21/67132

Informative references

Attention is drawn to the following places, which may be of interest for search:

Closure of boxes with tape

B65B 51/067

Foil dispensers

B65D 83/0847, B65D 85/672

{Article or web delivery apparatus incorporating cutting or line-perforating devices}
Definition statement

This place covers:

E.g. wall-mounted dispensers of film, foil or tape.

References
Limiting references

This place does not cover:

Wall-mounted dispensers of paper towels

A47K 10/32

Informative references

Attention is drawn to the following places, which may be of interest for search:

Foil dispensers also in

B65D 83/0805, B65D 85/672

{and applying the article or the web by adhesive to a surface (B65H 35/002 takes precedence)}
References
Limiting references

This place does not cover:

Hand-held or table apparatus

B65H 35/002

{Hand-held or table apparatus (B65H 35/006 takes precedence)}
References
Limiting references

This place does not cover:

Article or web delivery apparatus incorporating cutting or line-perforating devices with means for delivering a predetermined length of tape

B65H 35/006

{for delivering pressure-sensitive adhesive tape}
References
Limiting references

This place does not cover:

Application of wallpaper

B44C 7/02, B44C 7/06

Label dispensers

B65C 11/00

{and affixing it to a surface (B65H 35/004 takes precedence)}
References
Limiting references

This place does not cover:

Simultaneously with a second roll

B65H 35/004

Informative references

Attention is drawn to the following places, which may be of interest for search:

Closing of boxes

B65B 51/067

{simultaneously with a second roll, e.g. masking tape}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Masking elements e.g. strips of tape or sheets

B05B 12/24

{with means for moistening or coating the articles or webs, or applying adhesive thereto}
References
Limiting references

This place does not cover:

Applying mud to drywall tape

E04F 21/00

{using movable cutting elements}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Cutting with movable elements

B26D 1/045, B26D 1/065, B26D 1/105, B26D 1/345

from or with devices for breaking partially-cut or perforated webs, e.g. bursters
References
Limiting references

This place does not cover:

Machines for issuing tickets from a strip

G07B 3/02

Article or web delivery apparatus incorporating devices for performing specified auxiliary operations (incorporating cutting or line-perforating devices B65H 35/00)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Folding of thin sheet-like materials, special discharging devices, and others (FTCLA)

3F108

{Web delivery apparatus, the web serving as support for articles, material or another web}
References
Limiting references

This place does not cover:

Tools for inserting weather strips

B25B 27/0092

Informative references

Attention is drawn to the following places, which may be of interest for search:

Temporary attachment of articles

B42F 5/00

Processes for producing a decorative affect comprising an adhesive layer

B44C 1/105

{Hand-held apparatus}
Definition statement

This place covers:

E.g. door sash jigs

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Adhesive-tape dispensers (FICLA)

B65H35/07

Dispensing wound dressing e.g. plasters, bandages

A61F 15/002

Door sash jigs also found in

B60J 10/30, B23P 19/047

Label dispensing

B65C 11/004

{Applicators for applying coatings, e.g. correction, colour or adhesive coatings}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Erasing devices

B43L 19/00

for securing together articles or webs, e.g. by adhesive, stitching or stapling (adhering replacement to expiring web during change of web roll B65H 19/18)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Attaching sheets, webs or strips

B31F 5/00

Machines for collating and permanent attaching sheets

B42C 1/12

Special rules of classification

Stapler arrangements B65H 2408/12.

Associating, collating or gathering articles or webs (machines for both collating or gathering and permanently attaching together sheets or signatures B42C 1/00)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Combinations of piling and depiling operations, e.g. performed simultaneously, of interest apart from the single operation of piling or depiling as such

B65H 83/00

Rotary presses, namely collecting

B41F 13/64

Collating or gathering sheets combined with processes for permanently attaching together sheets or signatures or for interposing inserts

B42C 1/00

Special rules of classification

This main group should be used only for subject matter (i.e. associating, collating or gathering articles or webs) not being covered by any of its lower subgroups.

Associating,collating or gathering articles from several sources
Special rules of classification

This group should be used only for subject matter (i.e. associating, collating or gathering articles from several sources) not being covered by any of its lower subgroups.

from piles
Special rules of classification

This group should be used only for subject matter (i.e. associating, collating or gathering articles from several piles) not being covered by any of its lower subgroups.

the piles being disposed in superposed carriers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


the piles being disposed in juxtaposed carriers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media699.png

by collecting in superposed carriers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media700.png

by collecting in juxtaposed carriers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media701.png

from delivery streams
Special rules of classification

This group should be used only for subject matter (i.e. associating, collating or gathering articles from several delivery streams) not being covered by any of its lower subgroups.

by collecting in rotary carriers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media702.png

Relationships with other classification places

for rotary carriers as starwheel, also allocate B65H 29/40/EC

Associating articles from a single source, to form, e.g. a writing-pad {(laminating B32B 37/00, B32B 38/00)}
Definition statement

This place covers:

Associating articles from a single source to form e.g. a writing-pad.

Illustrative example of subject matter classified in this group:media703.png

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Methods or apparatus for laminating

B32B 37/00

Machines for both collating or gathering and permanently attaching together the sheets or signatures

B42C 1/12

Special rules of classification

This group should be used only for subject matter (i.e. associating, collating or gathering articles from a single source, e.g. to form a writing-pad) not being covered by any of its lower subgroups.

in juxtaposed carriers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media704.pngmedia705.png

Associating two or more webs
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:media706.png

Machines for separating superposed webs
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Treatment of layered products, namely delaminating

B32B 43/006

Use of control, checking, or safety devices, e.g. automatic devices comprising an element for sensing a variable
Definition statement

This place covers:

Aspects related to controlling the handling of articles after these have been subjected to a particular process, e.g.:

the concept that the handling conditions (for example the articles delivery speed) after a process influence or determine the conditions or settings of the process itself (for example the stopping time).

The sub-group also covers subject-matter which emphasizes the particular interface means applied or functioning between the process and the handling (for example delivery of articles) action; such interface means could be for example communication means between the delivery controller and process controller, or user interfaces like information input or displaying means linked to the delivery controller.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Aspects related to controlling the handling of articles before they arrive to a particular process

B65H 7/00

Aspects related to controlling the handling of webs

B65H 23/00, B65H 26/00

Special rules of classification

Because the sensing nowadays in the majority of cases is realized through photoelectric sensors, the majority of documents would have to be classified in B65H 43/08 if the IPC precedence notes were followed. In order to rationalize classification, the IPC note "B65H 43/08 takes precedence" is ignored.

The rules followed are the following:

Documents are first classified according to which part of the article or to which situation the feelers or detectors respond. If the sensor works with an photoelectrical element and the structural build up of the sensor is particularly emphasized, then the document is classified in B65H 43/08 as well.

Additionally, codes from B65H 5/00, as well as the indicators + B65H 2220/00(see Special Rules for Classification within B65H, Note 1, directed to the B65H scheme) should be given to further specify the control aspects.

Examples:

detecting, or responding to, absence of articles (B65H 43/08 takes precedence)
References
Limiting references

This place does not cover:

Photoelectric devices

B65H 43/08

detecting, or responding to, presence of faulty articles (B65H 43/08 takes precedence; diverting faulty articles from main streams B65H 29/62)
References
Limiting references

This place does not cover:

Photoelectric devices

B65H 43/08

Informative references

Attention is drawn to the following places, which may be of interest for search:

Article switches or diverters for diverting faulty articles from the main stream

B65H 29/62

detecting, or responding to, completion of pile (B65H 43/08 takes precedence)
References
Limiting references

This place does not cover:

Photoelectric devices

B65H 43/08

Informative references

Attention is drawn to the following places, which may be of interest for search:

Full amount (i.e., pile completed) as target parameter

3F048/BA04 (Japanese)

Folding thin material (specially adapted for the manufacture or treatment of particular products, see appropriate subclasses, e.g. D06F 89/00)
References
Limiting references

This place does not cover:

Plastic bags or sacks

B31B 70/26

Airbags

B60R 21/16

Informative references

Attention is drawn to the following places, which may be of interest for search:

Folding of webs for diapers

A61F 13/15682, A61F 13/15747

Forming fold lines by pressing or scoring

B29C 53/06

Folding sheets
References
Limiting references

This place does not cover:

Folding webs (B65H 20/28 takes precedence)
References
Limiting references

This place does not cover:

Mechanisms for delivering webs in superposed folds and refeeding them from the lower end of the folded assemblies

B65H 20/28

longitudinally
Definition statement

This place covers:

Includes longitudinal interfolding of webs.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Longitudinal folding in a rotary printing press

B41F 13/58

by a carriage which reciprocates above the laying station
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Laying of fleece-like material

D01G 25/00

Folding articles or webs with application of pressure to define or form crease lines (B65H 20/28 takes precedence; pleating, kilting or goffering textile fabrics D06J)
References
Limiting references

This place does not cover:

Mechanisms for delivering webs in superposed folds and refeeding them from the lower end of the folded assemblies

B65H 20/28

Rotary folders
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Folding bandages or dressings

A61F 13/15747

{Flying tuck folders}
Definition statement

This place covers:

Also known as Hypocycloidal folders.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Revolving pivotal folding blade (UCLA)

270/50

Planetary blade (UCLA)

493/431

Oscillating or reciprocating blade folders (carried on rotary members B65H 45/16)
Special rules of classification

With pressing of spine of folded material B65H 2701/13212

Zig-zag folders {(B65H 45/228 takes precedence)}
References
Limiting references

This place does not cover:

Longitudinal folders

B65H 45/228

Longitudinal folders, i.e. for folding moving sheet material parallel to the direction of movement
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

In a rotary printing press

B41F 13/56, B41F 13/58

Interfolding sheets, e.g. cigarette or toilet papers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Dispensing from interfolded stacks

A47K 10/42

Containers for interfolded stacks

B65D 83/0894

Unfolding thin limp material (B65H 20/28 takes precedence; opening devices for sheets or signatures B65H 5/30)
References
Limiting references

This place does not cover:

Mechanisms for delivering webs in superposed folds and refeeding them from the lower end of the folded assemblies

B65H 20/28

Unwinding or paying-out filamentary material; Supporting, storing or transporting packages from which filamentary material is to be withdrawn or paid-out (winding B65H 54/00; bobbins, tubes or other cores for packages B65H 75/00)
References
Limiting references

This place does not cover:

Unwinding webs

B65H 16/00

Winding

B65H 54/00

Flyer unwinding

B65H 57/20

Bobbins, tubes or other cores for packages

B65H 75/00

Storing and repeatedly paying-out and restoring lengths of material

B65H 75/34

Informative references

Attention is drawn to the following places, which may be of interest for search:

Wire spool supports for plants

A01G 9/126

Twine cutter with holder (shop accessories)

A47F 13/045

Unwinding or uncoiling metal wire or band

B21C 47/16

Containers, packaging elements or packages specially adapted for coils of wire, rope, or hose

B65D 85/04

Containers, packaging elements or packages specially adapted for other web or tape-like material

B65D 85/67

Supports for supply packages in twisting machines

D01H 1/18

Holders or supports for packages in knitting machines

D04B 15/40

Spool carriers in braiding or lacing machines

D04C 3/14

Bearing supports for supply bobbins or reels in rope or cable making machines

D07B 7/06

Unwinding wire in missiles

F42B 15/00

Methods or apparatus in which packages do not rotate
Definition statement

This place covers:

General methods or apparatuses for unwinding filamentary material from a non-rotating package not provided for in subgroups.

Package-supporting devices
Definition statement

This place covers:

Supports for non-rotating packages not provided for in subgroups.

for a single operative package
Definition statement

This place covers:

Supports for holding a single operative non-rotating package


References
Limiting references

This place does not cover:

Securing the non-rotating package to the support for unwinding

B65H 49/36

Expandable spindles in general

B65H 75/242

Special rules of classification

Also contains transport caddies which are generally not only used for transporting cops (B65H 67/06) but also for supporting the cops in the unwinding position:


enclosing the package
Definition statement

This place covers:

Containers (with or without supportive core) for unwinding filamentary material, e.g. welding wire:


References
Limiting references

This place does not cover:

Guides for assisting paying-out

B65H 57/00

Rings on top of package

B65H 57/18

Devices acting on material leaving the package for adjusting or controlling tension

B65H 59/06

Storing in cans or receptacles

B65H 75/16

Informative references

Attention is drawn to the following places, which may be of interest for search:

Dereeling means for electrodes in arc welding

B23K 9/1333

Containers, packaging elements or packages specially adapted for coils of wire, rope, or hose

B65D 85/04

Containers for unwinding yarn packages for knitting or crochet

D04B 3/06

for one operative package and one or more reserve packages
Definition statement

This place covers:

With changing operative position when switching to the reserve package


the reserve packages being mounted to permit manual or automatic transfer to operating position
Definition statement

This place covers:

With a mechanism to transfer the reserve packages to the operating position media213.png

for several operative packages
Special rules of classification

This class is not used. Use B65H 49/16.

Stands or frameworks
Definition statement

This place covers:

Stands or frameworks for several operative non-rotating packages, e.g. creels media214.png


References
Limiting references

This place does not cover:

Stands or frameworks for rotating packages

B65H 49/32

Informative references

Attention is drawn to the following places, which may be of interest for search:

Creels

D02H 1/00

Frames or assemblies of two or more reels in knitting machines

D04B 15/42

Methods or apparatus in which packages rotate (flyers or other guides assisting paying-out B65H 57/00; supports or holders, for storing and repeatedly paying-out and rewinding lengths of material provided for particular purposes B65H 75/34)
Definition statement

This place covers:

General methods or apparatuses for unwinding filamentary material from a rotating package not provided for in subgroups, e.g. methods or devices for aligned or orderly unwinding e.g. with pivoting or axially movable reel

References
Limiting references

This place does not cover:

Flyers or other guides for assisting paying-out

B65H 57/00

Supports or holders, for repeatedly paying-out and rewinding length of material provided for particular purpose

B65H 75/34

Package-supporting devices
Definition statement

This place covers:

Supports for rotating packages not provided for in subgroups

{Hand-held or portable dispensers}
Definition statement

This place covers:

Small, hand-held or belt supported dispensers, e.g. for dispensing binding wire or string.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Fly tying devices

A01K 97/26

Containers or dispensers for dental floss

A61C 15/043

Overhead suspension devices
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Rollers
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Axial shafts or spigots
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Turntables {, i.e. package resting on a table (having also means for clamping the package B65H 49/30)}
Definition statement

This place covers:

Packages resting on a rotating table.


References
Limiting references

This place does not cover:

Swifts or skein holders

B65H 49/30

Swifts or skein holders
Definition statement

This place covers:

Rotating (e.g. around a horizontal or vertical axis) holders for unwinding packages provided as coreless coils.


{with axially adjustable or removable elements for retaining the package}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


Stands or frameworks
Definition statement

This place covers:

Details with regard to the stand or framework supporting the package(s). media225.pngmedia226.jpg

References
Limiting references

This place does not cover:

Stands or frameworks for non-rotating packages

B65H 49/16

Informative references

Attention is drawn to the following places, which may be of interest for search:

Racks

A47B 43/00- A47B 57/00

Show stands or shelves for flexible long articles in rolls

A47F 7/005

Show stands or shelves for carpets, wallpaper or fabrics in rolls

A47F 7/175

{characterised by features enabling their folding or dismantling}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Enclosing boxes with supporting means for the package or reel during unwinding}
Definition statement

This place covers:

E.g. cassettes to be used in machinery, or cardboard boxes with a rotating reel


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Containers, packaging elements or packages specially adapted for coils of wire, rope, or hose

B65D 85/04

{Constructional details}
Special rules of classification

Not used, use either subgroups or B65H 49/32.

{Arrangements or adaptations for supporting the shafts, e.g. saddle type shaft bearings}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Slot arrangements e.g. saddle bearings for web rolls

B65H 2301/41306

Dispensers for paper towels or toilet paper

A47K 10/32

{Arrangements or adaptations for attachment to a wall, a post or the like}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Arrangements or adaptations for stacking}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for effecting positive rotation of packages
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Loop control while feeding stock to a tool

B21D 43/022

Securing packages to supporting devices (arrangements for applying packages to, or removing from, supports B65H 65/00, B65H 67/00)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Arrangements for applying packages to, or removing from, supports

B65H 65/00, B65H 67/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Securing cores or formers for winding filamentary material

B65H 54/543

Expansible spindles, mandrels or chucks, e.g. for securing or releasing cores, holders or packages for filamentary or web-like material

B65H 75/242

Skips, cages, racks, or containers, adapted solely for the transport or storage of bobbins, cops, or the like
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Vehicles for transporting reel units

B60P 3/035

Forwarding filamentary material (stretch-spinning methods D01D 5/12; drawing or drafting rovings or the like D01H 5/00)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Feeding devices for metal wire or band

B21C 47/34

Feeding wire in wire-working machines

B21F 23/00

Devices for feeding saw wire

B23D 57/0061

Solder feeding devices

B23K 3/06

Means for feeding electrodes

B23K 9/133

Apparatus or processes specially adapted for manufacturing, assembling, maintaining, or repairing of line connectors or current connectors or for joining electric conductors of trolley lines

B60M 1/28, H01R 43/00

Stretch-spinning methods

D01D 5/12

Drawing or drafting rovings or the like

D01H 5/00

Devices for feeding threads to the needles in knitting

D04B 15/38

Apparatus or processes specially adapted for manufacturing, assembling, maintaining, or repairing of line connectors or current connectors or for joining electric conductors (joining cables)

H02G 1/14, H01R 43/00

Separating a bundle of forwarding filamentary materials into a plurality of groups
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Thread sheets, e.g. sheets of parallel yarns or wires

B65H 2701/38

Opening bundles to space the threads or filaments

D01D 11/02

Separating or spreading

D02J 1/18

by means of static electricity
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Gathering a plurality of forwarding filamentary materials into a bundle
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Thread sheets, e.g. sheets of parallel yarns or wires

B65H 2701/38

Rotary devices, e.g. with helical forwarding surfaces (devices for temporarily storing filamentary material during forwarding B65H 51/20; driven rotary devices for controlling tension B65H 59/18)
Definition statement

This place covers:

E.g. guiding surface on the inside of the forwarding element.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Devices for temporarily storing filamentary material during forwarding

B65H 51/20

Driven rotary devices for controlling tension

B65H 59/18

Rollers, pulleys, capstans, or intermeshing rotary elements
References
Limiting references

This place does not cover:

Guides as pulleys, rollers or rotary bars (not driven)

B65H 57/14

arranged to operate singly
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


arranged to operate in groups or in co-operation with other elements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with opposed coacting surfaces, e.g. providing nips
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Adjusting or controlling tension in filamentary material by braked elements rotated by material

B65H 59/16

Adjusting or controlling tension in filamentary material by co-operating surfaces mounted for relative movement and arranged to apply pressure to material

B65H 59/22

{one of which is an endless belt}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


in spaced relation to provide a series of independent forwarding surfaces around which material is passed or wound
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Stretching or tensioning, shrinking or relaxing, e.g. by use of overfeed and underfeed apparatus

D02J 1/225

Heating or cooling the yarn, thread, cord, rope or the like by contact with at least one rotating roll

D02J 13/005

Aprons, endless belts, lattices, or like driven elements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Devices for entraining material by flow of liquids or gases, e.g. air-blast devices (blowing slag wool in molten state C03B 37/06)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Blowing slag wool in molten state

C03B 37/06

Gripping devices with linear motion
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Devices for temporarily storing filamentary material during forwarding, e.g. for buffer storage
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Devices for temporarily accumulating metal wire or band

B21C 49/00

{by means of a fluid}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Adjusting or controlling tension in filamentary material, by devices acting on running material and not associated with supply or take-up devices, the material being subjected to the action of a fluid

B65H 59/105

Regulating tension by devices acting on running yarn and not associated with supply or take-up devices

D01H 13/104

Device for measuring and temporary storing the weft

D03D 47/36

Thread-feeding devices

D04B 15/48

Reels or cages, e.g. cylindrical, with storing and forwarding surfaces provided by rollers or bars {(measuring and temporaly storing the weft in looms D03D 47/36; thread feeding devices for weft knitting machines D04B 15/48)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

Temporary storage associated with textile machines other than weaving or knitting machines can be found by crossing the group with the subclass of the other textile field e.g. with D05B, D05C or D01H.

References
Limiting references

This place does not cover:

Measuring and cutting the weft. Devices for measuring and temporary storing the weft

D03D 47/36

Thread-feeding devices in knitting

D04B 15/48

Informative references

Attention is drawn to the following places, which may be of interest for search:

Regulating tension by devices acting on running and not associated with supply or take-up devices in twisting or spinning

D01H 13/104

with interdigitating bars
Definition statement

This place covers:

Not used for classification.

References
Limiting references

This place does not cover:

In weaving

D03D 47/36

In Knitting

D04B 15/48

Rollers or bars mounted askew to facilitate movement of filamentary material along them, e.g. pairs of canted rollers
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Devices controlling the forwarding speed to synchronise with supply, treatment, or take-up apparatus (B65H 59/10, B65H 59/38 take precedence)
Definition statement

This place covers:

E.g. stopping unwinding when take-up stops, or control of welding wire speed (see figure).


Relationships with other classification places

Thread feeding or tensioning arrangement.

References
Limiting references

This place does not cover:

Adjusting or controlling tension in filamentary material by devices acting on running material

B65H 59/10

Adjusting or controlling tension in filamentary material by regulating speed of driving mechanism of unwinding, paying-out, forwarding, winding or depositing devices

B65H 59/38

Positive yarn feeders in knitting

D04B 15/48

Thread feeding or tensioning arrangements in embroidering

D05C 15/18

Informative references

Attention is drawn to the following places, which may be of interest for search:

Adjusting or controlling tension in filamentary material by regulating delivery of material from supply package

B65H 59/02

Supporting or driving arrangements for forwarding devices
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Winding, coiling, or depositing filamentary material (cores, formers, holders, cans or receptacles B65H 75/02)
Definition statement

This place covers:

In particular devices and processes also classified in other parts of B65H and including winding of yarns not provided in subgroups.

Relationships with other classification places

Continuous winding on two or more winding heads in succession

References
Limiting references

This place does not cover:

Winding webs

B65H 18/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Cores, formers, holders, cans or receptacles

B65H 75/02

Winding or coiling up metal wire or band

B21C 47/02

Slubbing-winding apparatus

D01G 15/62

Lap- or sliver-winding devices

D01G 27/00

Winding finished rope or cable in cable or rope making

D07B 7/10

{Hank to spool winders}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Doubling winders, i.e. for winding two or more parallel yarns on a bobbin, e.g. in preparation for twisting or weaving}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


for making packages with closely-wound convolutions
Special rules of classification

Only used if not classified in: Arrangements for aligned winding: B65H 54/2848

for making cross-wound packages
References
Limiting references

This place does not cover:

Traversing devices

B65H 54/28

Precision winding arrangements
References
Limiting references

This place does not cover:

Preventing ribbon winding in a precision winding apparatus

B65H 54/381

for making packages of specified shapes or on specified types of bobbins, tubes, cores, or formers
Definition statement

This place covers:

Winding packages not provided for in subgroups.

{forming frusto-conical packages or forming packages on frusto-conical bobbins, tubes, cores or formers}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Manual or other small, compact or portable winding devices for forming packages for different purposes}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Cores, formers, supports or holders for wound material hand-held during use

B65H 75/406

on flanged bobbins or spools (B65H 54/20 takes precedence)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Winding forming multiple packages

B65H 54/20

on tubes, cores, or formers having generally parallel sides, e.g. cops or packages to be loaded into loom shuttles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


forming bottle bobbin packages
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


forming multiple packages
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Traversing devices with a plurality of guides for winding on a plurality of bobbins

B65H 54/2881

{the winding material being continuously transferred from one bobbin to the adjacent one}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Automatic winding machines, i.e. machines with servicing units for automatically performing end-finding, interconnecting of successive lengths of material, controlling and fault-detecting of the running material and replacing or removing of full or empty cores
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements for removing completed take-up packages and/or replacing by cores, formers, or empty receptacles at winding or depositing stations; Transferring material between adjacent full and empty take-up elements

B65H 67/04

Other common constructional features, details of accessories (spinning)

D01H 13/00

having a plurality of winding units moving along an endless path past one or more fixed servicing units
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


having one or more servicing units moving along a plurality of fixed winding units
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Traversing devices; Package-shaping arrangements (arrangements for preventing ribbon winding B65H 54/38; grooved, slotted, or split drums for driving of packages B65H 54/46)
References
Limiting references

This place does not cover:

Guiding of cables in winches and capstans

B66D 1/38

Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements for preventing ribbon winding

B65H 54/38

Grooved, slotted or split drums for driving of packages

B65H 54/46

Package-shaping arrangement in spinning

D01H 1/36

Traversing arrangements

D01H 13/06

Special rules of classification

Guides per se or arrangements for mounting the guide on the traversing mechanism: B65H 57/006.

{with a traversely moving package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Traversing devices driven by cam}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



{rotating grooved cam (driving split drums B65H 54/50)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Driving split drums

B65H 54/50

{with a traversing guide running in the groove}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{heart-shaped cam}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Traversing devices driven by rod}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Traversing devices driven by belts or chains (B65H 54/2836 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Traversing devices with a rotating guide for traversing the yarn

B65H 54/2836

{with at least two traversing guides travelling in opposite directions}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Traversing devices with a pivotally mounted guide arm}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Traversing devices driven by pneumatic or hydraulic means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Traversing devices driven by electromagnetic means}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Motors with reciprocating magnets

H02K 33/00

Propulsion systems in which a rigid body is moved along a path due to a magnetic field

H02K 41/00

{with a rotating guide for traversing the yarn}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Special rules of classification

Multiple guides attached to one or more endless belts or chains wherein the yarn is transferred between the guides: B65H 54/2821.

{counter rotating guides, e.g. wings}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{grooved, slotted, or split drums}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:




References
Limiting references

This place does not cover:

Package drive drums

B65H 54/46

{"screw" type Owens Fiberglas}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Fiberglass strands

B65H 2701/312

Manufacture or treatment of flakes, fibres, or filaments from softened glass, minerals, or slags

C03B 37/00

{Arrangements for aligned winding (reels with grooves or grooved elements for aligned winding B65H 75/265)}
Definition statement

This place covers:

For example:

  • Manually operated devices


  • Devices where the traversing movement follows a pattern


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Reels with grooves or grooved elements for aligned winding

B65H 75/265

{by pressing the material being wound against the drum, flange or already wound material, e.g. by fingers or rollers; guides moved by the already wound material (B65H 54/2869 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Control of the rotating speed of the reel or the traversing speed for aligned winding

B65H 54/2869

{Detection or control of aligned winding or reversal}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Reversal control}
Definition statement

This place covers:

E.g. reversal determined by the position or thickness of the material or its distance to the flange e.g. calculated by a microprocessor.


{by detection of position, or distance made of the traverser}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Control of the rotating speed of the reel or the traversing speed for aligned winding}
Definition statement

This place covers:

E.g. calculating the traversing speed from the diameter of the material and other parameters relating to the reel.

{by detection of the incidence angle}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by detecting or following the already wound material, e.g. contour following}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by detection of incorrect conditions on the wound surface, e.g. material climbing on the next layer, a gap between windings}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Incorrect conditions are often detected from the speed variation of the material.

{Traversing devices with a plurality of guides for winding on a plurality of bobbins (forming multiple packages B65H 54/20)}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding filamentary material forming multiple packages

B65H 54/20

{Microprocessor-controlled traversing devices in so far the control is not special to one of the traversing devices of groups B65H 54/2803 - B65H 54/325 or group B65H 54/38}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Superposed traversing, i.e. traversing or other movement superposed on a traversing movement}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Flyers}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with thread guides reciprocating or oscillating with fixed stroke {(B65H 54/2803 - B65H 54/2896 take precedence)}
Special rules of classification

This class is not used any more.

with thread guides reciprocating or oscillating with variable stroke
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{in accordance with growth of the package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


for laying subsidiary winding, e.g. transfer tails
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding reserve length in spinning machines

D01H 1/38

{when starting winding on an empty bobbin}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Securing materials to cores or formers

B65H 65/00

{on or outwardly of the fully wound yarn package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Securing end of yarn in the wound or completed package

B65H 65/005

Yarn-guide advancing or raising mechanisms, e.g. cop-building arrangements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{for cops of pirn winding machine (B65H 54/14 takes precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Winding filamentary material on tubes, cores or formers having generally parallel sides

B65H 54/14

Arrangements for preventing ribbon winding {; Arrangements for preventing irregular edge forming, e.g. edge raising or yarn falling from the edge}
Definition statement

This place covers:

In random winding (constant traversing frequency, constant winding angle, decreasing winding rotational speed, decreasing winding ratio) the winding ratio continuously decreases, thereby causing "mirror windings" at certain winding ratios. Devices and methods for preventing such mirror windings other than by "precision winding" or "stepped precision winding" are classified here. See US5447277 and XP000409312 for an explanation of precision winding, stepped precision winding and random winding.


{Preventing ribbon winding in a precision winding apparatus, i.e. with a constant ratio between the rotational speed of the bobbin spindle and the rotational speed of the traversing device driving shaft}
Definition statement

This place covers:

In precision winding the winding ratio (ratio of rotational speed to traversing frequency) is constant. Therefore, since the winding rotational speed decreases with increasing diameter of the package, the traversing frequency also decreases. The winding angle therefore also decreases with increasing diameter. Since the winding ratio is constant, "mirror windings" at certain winding ratios are avoided.


{in a stepped precision winding apparatus, i.e. with a constant wind ratio in each step}
Definition statement

This place covers:

In stepped precision winding the winding ratio K (ratio of rotational speed to traversing frequency) is decreasing stepwise (constant) around a decreasing winding ratio as would be obtained in random winding to avoid "mirror windings" at certain winding ratios. The winding angle can still be kept constant as in random winding.



{Preventing edge raising, e.g. creeping arrangements}
Definition statement

This place covers:

E.g. oscillating traversing width:


E.g. apparatus providing such oscillations:


{with energy storing means for recovering the kinetic energy at the end of the traversing stroke}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Preventing the yarn from falling off the edge of the package}
Definition statement

This place covers:

Guides and traversing control.


in which the package, core, or former is rotated by frictional contact of its periphery with a driving surface
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


in which the package, core, or former is engaged with, or secured to, a driven member rotatable about the axis of the package
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Package drive drums
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Grooved drums
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{with an auxiliary guide}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Slotted or split drums
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Drive contact pressure control, e.g. pressing arrangements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Securing cores or holders to supporting or driving members, e.g. collapsible mandrels}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Securing cores or formers for unwinding filamentary material

B65H 49/36

Expansible spindles, mandrels or chucks, e.g. for securing or releasing cores, holders or packages for filamentary or web-like material

B65H 75/242

Arrangements for coupling bobbins or the like to spindles (Spinning)

D01H 7/16

Cantilever supporting arrangements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Both-ends supporting arrangements
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Swifts or reels adapted solely for the formation of hanks or skeins (B65H 49/30 takes precedence)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Swifts or skein holders for unwinding filamentary material

B65H 49/30

{Reels for rolling tape-like material, e.g. flat hose or strap, into flat spiral form; Means for retaining the roll after removal of the reel}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding straps for securing loads

B60P 7/0846

Binding of skeins
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Bundling particular articles presenting special problems using string, wire, or narrow tape or band; Baling fibrous material, e.g. peat, not otherwise provided for

B65B 27/00

Bundling coils of wire or like annular objects

B65B 27/06

Winding of balls; {(forming hollow objects by winding on to fusible or soluble cores, e.g. forming pressure vessels B29C 53/56)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Forming hollow objects by winding on to fusible or soluble cores

B29C 53/56

Winding yarns into balls
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Winding on to cards or other flat cores, e.g. of star form
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Arrangements for confining or removing dust (for spinning D01H 11/00; cleaning in general B08B)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Cleaning in general

B08B

For spinning

D01H 11/00

For weaving

D03J 1/002

For knitting

D04B 35/32

{Suction generating system}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for severing filamentary materials
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Framework; Casings; Coverings
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Driving arrangements (arrangements for preventing ribbon winding B65H 54/38; arrangements for rotating packages B65H 54/40)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements for preventing ribbon winding

B65H 54/38

Arrangements for rotating packages

B65H 54/40

Depositing materials in cans or receptacles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Folding webs in combination with laying, forming a zig-zag pile

B65H 45/101

Lap-forming devices in preliminary treatment of fibres

D01G 25/00

Fibres being oriented in non woven fabrics

D04H 1/74

Apparatus in which the depositing device or the receptacle is reciprocated
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Apparatus in which the depositing device or the receptacle is rotated
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


and in which coils are formed before deposition
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for compacting materials in receptacles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for taking-up waste material before or after winding or depositing
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by means of pneumatic arrangements, e.g. suction guns
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Automatic end-finding and material interconnection arrangements

B65H 67/08

Threading up and starting the false-twisting machine for producing crimped or curled fibres

D02G 1/0273

Wound packages of filamentary material
Definition statement

This place covers:

Wound packages of filamentary material not provided for in subgroups.

{with two or more filaments wound in parallel on the bobbin}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Self-supporting packages
Definition statement

This place covers:

Packages without a core.



characterised by method of winding
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{the yarn paying off through the centre of the package}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{packages having a radial opening through which the material will pay off}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Guides for filamentary materials; Supports therefor
Definition statement

This place covers:

Contains for ex. documents relating to guiding methods e.g. how the yarn is guided between unwinding and winding station.



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Guides for slivers, rovings or yarns in spinning machines

D01H 13/04

Handling the weft between bulk storage and weft-inserting means in weaving looms

D03D 47/34

Thread guides in weft knitting machines

D04B 15/54

Guides in thread-tensioning arrangements in embroidering machines

D05C 11/08

{Arrangements for threading or unthreading the guide}
Definition statement

This place covers:

Arrangements and methods for threading or unthreading the guide.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Apparatus for threading warp stop-motion droppers, healds, or reeds

D03J 1/14

{Traversing guides}
Definition statement

This place covers:

Details of the guide of a traversing device.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Traversing devices

B65H 54/28

Traversing arrangements for guides in spinning machines

D01H 13/06

Stationary rods or plates
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Guiding surfaces within slots or grooves
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Annular guiding surfaces; Eyes, e.g. pigtails
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



formed of wire or the like
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



with flared apertures
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:




Tubes
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Coiling metal wire by means of a rotating guide tube

B21C 47/143

Guide tubes for slivers, rovings or yarns in spinning machines

D01H 13/045

Laying electric cables trough tubing or conduit

H02G 1/08

Installation of electric cables in underground tubes or conduits

H02G 9/06

Pulleys, rollers, or rotary bars
Definition statement

This place covers:

Freely rotating pulleys, rollers or rotary bars.


References
Limiting references

This place does not cover:

Driven rollers, pulleys, capstans or intermeshing rotary elements for forwarding filamentary material

B65H 51/04

Informative references

Attention is drawn to the following places, which may be of interest for search:

Guiding of ropes, cables or chains in winding mechanism

B66D 1/36

Supporting moving filaments during manufacture using rollers with mutually inclined axes

D01D 10/0445

Producing crimped or curled fibers, filaments, yarns or threads by false-twisting

D02G 1/02

formed to maintain a plurality of filaments in spaced relation
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Thread sheet, e.g. sheet of parallel yarns or wires

B65H 2701/38

Physical treatment of artificial filaments, the filaments being maintained parallel

D01D 10/0463

Reeds or combs for determining the spacing of threads in warping or beaming arrangements

D02H 13/16

Guiding means preventing threads from sticking together in textile treating arrangements

D06B 23/06

mounted to facilitate unwinding of material from packages
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Guides for aligned unwinding from rotating bobbins

B65H 57/28

Informative references

Attention is drawn to the following places, which may be of interest for search:

Tension devices acting on the material leaving the package

B65H 59/06

Dereeling means for welding wire, e.g. retaining plate

B23K 9/1333

Means to facilitate the unwinding of the yarn in twisting

D01H 7/866

Flyers (for inserting twist D01H)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Axially movable following in alignment the point at which the material leaves the package

B65H 57/28

Informative references

Attention is drawn to the following places, which may be of interest for search:

Flyers for inserting twist

D01H

adapted to prevent excessive ballooning of material
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Anti-ballooning devices in spinning or twisting machines

D01H 1/42

Arrangements on spinning spindles for suppressing yarn balloons

D01H 7/18

Anti-ballooning devices on spindles for spinning or twisting arrangements

D01H 7/18

Yarn braking means acting on the drum of a weft feeder for a weaving loom

D03D 47/364

Supports for guides
Definition statement

This place covers:

'Characterised by its support' e.g. swing-over or turn-over supports.

Devices supporting multiple guides.


Reciprocating or oscillating guides (traversing devices for winding, coiling, or depositing filamentary material B65H 54/28)
Definition statement

This place covers:

Reciprocating or oscillating other than for B65H 54/28 e.g. guides following the traversing motion of the material leaving the reel.

Contains pivoting or oscillating guides supported by a traversing mechanism but not influencing the traversing (superposed traversing movements B65H 54/2893).


References
Limiting references

This place does not cover:

Traversing devices for winding, coiling or depositing filamentary material

B65H 54/28

Adjusting or controlling tension in filamentary material, e.g. for preventing snarling; Applications of tension indicators
Definition statement

This place covers:

Methods and devices related to adjusting or controlling tension not provided for in subgroups.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Regulation of tension or speed for winding metal wire or band

B21C 47/003

Devices for tensioning saw wires

B23D 57/0069

Wire-electrode tension control

B23H 7/104

Tension devices in spinning and twisting

D01H 13/10

Tensioning devices in warping, beaming or leasing machines

D02H 13/22

Control of tension in a warp supplied by a creel

D03D 49/16

Tensioning devices in knitting

D04B 15/44, D04B 27/12, D04B 27/14

Thread tensioning arrangements in embroidering or tufting

D05C 11/08

Tensioning in making pile fabrics

D05C 15/18

Brakes or tension regulating means in cables, conductors or insulators

H01B 13/0866

Tensioning or braking devices in winding magnets, inductances or transformers

H01F 41/094

{Means compensating the yarn tension in relation with its moving due to traversing arrangements}
Definition statement

This place covers:

Means which compensate variation in tension due to varying length of the yarn in the traversing triangle, e.g. curved rods, length accumulators or control means for controlling the winding, forwarding or unwinding speed.



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

By controlling speed of the driving mechanism of unwinding, payout or forwarding devices

B65H 59/38

by regulating delivery of material from supply package (by contact of package with support B65H 49/02; by controlling speed of driving mechanism of unwinding or paying-out devices B65H 59/38)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

By contact of package with support

B65H 49/02

Controlling the forwarding speed to synchronise with supply, treatment or take-up apparatus

B65H 51/30

By controlling speed of the driving mechanism of unwinding, payout or forwarding devices

B65H 59/38

by devices acting on package or support
Definition statement

This place covers:

E.g. devices which induce drag on the package or support by friction, rheological or magnetic effects.



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Spool carriers in braiding or lacing machines

D04C 3/14

Brakes for supply bobbins or reels in rope or cable making machines

D07B 7/06

{with a braking force varying proportionally to the diameter or the weight of the package being unwound}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


{varying proportionally to the weight only}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



by devices acting on material leaving the package
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Guides mounted to facilitate unwinding of material from packages

B65H 57/18

Means to facilitate the unwinding of the yarn in twisting

D01H 7/866

Yarn braking device acting on a weft feeding drum

D03D 47/364

Yarn braking means acting on the drum in knitting

D04B 15/484

by contact of running length of material with supply package
Definition statement

This place covers:

Running length of material is contacting the package, e.g. by wrapping around the package.


by devices acting on running material and not associated with supply or take-up devices (by controlling speed of driving mechanism of material-forwarding devices B65H 59/38)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Tension devices in spinning and twisting acting on the running yarn

D01H 13/106

{the material being subjected to the action of a fluid}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Devices for temporarily storing filamentary material during forwarding by means of a fluid

B65H 51/205

Stationary elements arranged to deflect material from straight path
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


and provided with surfaces imposing additional retarding forces on material
Definition statement

This place covers:

Additional measures to increase friction on the contact area of deflection. media401.png

Braked elements rotated by material
Definition statement

This place covers:

Rollers with drag (e.g. magnetic, friction or rheological) driven by the yarn. media402.png

Driven rotary elements (material-forwarding devices B65H 51/00)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Material forwarding devices

B65H 51/00

Co-operating surfaces mounted for relative movement
Definition statement

This place covers:

Co-operating surfaces mounted for relative movement not provided for in subgroups.

and arranged to apply pressure to material
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Tensioning devices for double twist spindle

D01H 13/106

{Tension discs}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Surfaces movable automatically to compensate for variation in tension
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Automatically

Involving active elements such as actuators

and arranged to deflect material from straight path
Definition statement

This place covers:

Arranged to deflect material from straight path with surfaces not urged towards or away from each other.

the surfaces being urged towards each other
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Surfaces movable automatically to compensate for variation in tension
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Automatically

Involving active elements such as actuators

the surfaces being urged away from each other
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Surfaces movable automatically to compensate for variation in tension
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Automatically

Involving active elements such as actuators

Floating elements compensating for irregularities in supply or take-up of material (buffer storage devices B65H 51/20)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Buffer storage device

B65H 51/20

by regulating speed of driving mechanism of unwinding, paying-out, forwarding, winding, or depositing devices, e.g. automatically in response to variations in tension
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Controlling the forwarding speed to synchronise with supply, treatment or take-up apparatus

B65H 51/30

{using pneumatic or hydraulic means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using mechanical means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using electronic means}
Definition statement

This place covers:

Electronic control other than winding, unwinding and forwarding, e.g. traversing speed.

References
Limiting references

This place does not cover:

Loop control in advancing work to the die or other tool

B21D 43/022

{Regulating winding speed}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Regulating unwinding speed}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Regulating forwarding speed}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Thread-feeding devices in knitting

D04B 15/48

Applications of tension indicators
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Measuring tension in ropes, cables, wires, threads or the like

G01L 5/04

Applications of devices for metering predetermined lengths of running material (of general application G01B)
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Counting, measuring, recording or registering devices in spinning machines

D01H 13/32

Measuring length in general

G01B

{for measuring speed of running yarns}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Measuring linear or angular speed

G01P 3/00

Warning or safety devices, e.g. automatic fault detectors, stop-motions (safety devices in general F16P; indicating devices in general G08B ){; Quality control of the package}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Warning and safety devices in spinning

D01H 13/14

Warning and safety devices in warping/beaming

D02H 13/02

Warning and safety devices in weaving

D03D 51/18

Warning and safety devices in knitting

D04B 35/10

Safety devices in general

F16P

Measuring optically length, thickness, diameter

G01B 11/00

Investigating presence of flaws or contamination

G01N 21/88

Prediction of the effect of yarn quality on the final textile

G01N 33/36

Indicating devices in general

G08B

{responsive to winding of yarns around rotating cylinders}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{quality control of the package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


characterised by the detecting or sensing element
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


e.g. mechanical.

electrical or pneumatic
Definition statement

This place covers:

Detecting or sensing elements not provided for in subgroups.

{using electronic actuators}
Definition statement

This place covers:

Also contains the devices using indifferently more than one of the sensing means types provided in subgroups.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Investigating or analysing materials by specific methods not covered by the preceding groups - filiform textiles

G01N 33/365

{using capacitor sensing means, i.e. the defect signal is a variation of impedance}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using photo-electric sensing means, i.e. the defect signal is a variation of light energy}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Warning or safety devices responsive to reduction in material tension, failure of supply or breakage of material characterized by photo-electric sensing means

D01H 13/165

Investigating or analysing materials by the use of optical means for non-woven textile material

G01N 21/8915

{using fluid sensing means, e.g. acoustic}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using piezo-electric sensing means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using pneumatic sensing means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by a plate separating the package from the driving drum}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by lifting or raising the package away from the driving roller}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Braking means for the raised or lifted package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by clutching or de-clutching the package from its driving means (package secured to a rotary driven member)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


responsive to presence of irregularities in running material, e.g. for severing the material at irregularities {Control of the correct working of the yarn cleaner}
Definition statement

This place covers:

Control processes and apparatuses not provided for in subgroups.

{Mechanical slub catcher and detector}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Electronic slub detector}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Warning or safety devices responsive to presence of irregularities in running material

D01H 13/22

Investigating or analysing material by specific methods not covered by the preceding groups for filiform textiles

G01N 33/365

{using capacitor sensing means, i.e. the defect signal is a variation of impedance}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using photo-electric sensing means, i.e. the defect signal is a variation of light energy}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Measuring arrangements characterized by the use of optical means for measuring of diameters of objects while moving using photoelectric detection means

G01B 11/105

{using fluid sensing means, e.g. acoustic}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using piezo-electric sensing means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


responsive to delivery of a measured length of material, completion of winding of a package, or filling of a receptacle
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{responsive to a predetermined size or diameter of the package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{responsive to a predetermined weight of the package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{responsive to completion of unwinding of a package}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Clamping device (connected with slub-catcher B65H 63/061)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Connected with slub-catcher

B65H 63/061

Securing material to cores or formers (arrangements for securing ends of material to cores, formers, supports or holders, e.g. reels, B65H 75/28)
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Laying a subsidiary winding, e.g. transfer tails

B65H 54/34

Informative references

Attention is drawn to the following places, which may be of interest for search:

Loading a starter winding on an empty core

B65H 67/0422

Continuous winding apparatus for winding on two or more winding heads in succession

B65H 67/048

Arrangements for securing ends of material to cores, formers, supports or holders, e.g. reels

B65H 75/28

Arrangements for winding reserve lengths of yarn on take-up packages or spindles. e.g. transfer tails in spinning or twisting machines

D01H 1/38

{Securing end of yarn in the wound or completed package}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements for removing completed packages

B65H 67/0411

Replacing or removing cores, receptacles, or completed packages at paying-out, winding, or depositing stations
References
Limiting references

This place does not cover:

Changing web rolls

B65H 19/00

Transferring coils to or from winding apparatus in winding or unwinding metal wire or band

B21C 47/24

In carding

D01G 15/46, D01G 27/04

In spinning and twisting

D01H 9/00

Special rules of classification

Replacing the cross-wound package in spinning and twisting are classified in B65H 67/00 and subgroups.

Arrangements for removing spent cores or receptacles and replacing by supply packages at paying-out stations ({for cans D01H 9/008; arrangement of the service carriage B65H 54/26; } supports for packages B65H 49/04, B65H 49/20)
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


Relationships with other classification places

Supply to and transport from the unwinding position B65H 67/06.

References
Limiting references

This place does not cover:

Supports for packages

B65H 49/04, B65H 49/20

For cans

D01H 9/008

Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangement of the service carriage

B65H 54/26

Arrangements for removing completed take-up packages and {or} replacing by cores, formers, or empty receptacles at winding or depositing stations; Transferring material between adjacent full and empty take-up elements {(arrangement of the service carriage B65H 54/26)}
Definition statement

This place covers:

Transferring material between adjacent full and empty take-up elements.



Relationships with other classification places

Securing material to core or formers:B65H 65/00.

Arrangements for securing ends of material to cores or formers:B65H 75/28.

Continuous winding apparatus for winding on two or more winding heads in succession: B65H 67/044.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements of the service carriage

B65H 54/26

Special rules of classification

Details with regard to the arrangements for removing the take-up package and/or replacing by cores are classified in B65H 67/0405 and subgroups.

{Arrangements for removing completed take-up packages or for loading an empty core (B65H 67/044 takes precedence)}
Definition statement

This place covers:

Arrangements for removing completed take-up package as well as for loading an empty core.


References
Limiting references

This place does not cover:

Continuous winding apparatus for winding on two or more winding heads in succession

B65H 67/044

Special rules of classification

Arrangements for only removing completed take-up package are classified in B65H 67/0411.

Arrangements for only loading an empty core are classified in B65H 67/0417.

{for removing completed take-up packages}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{for loading an empty core}
Definition statement

This place covers:

Loading an empty core at the winding position.


{for loading a starter winding, i.e. a spool core with a small length of yarn wound on it; preparing the starter winding}
Definition statement

This place covers:

E.g. when replacing cross-wound packages in spinning machines, the empty core is provided with a starter winding from an auxiliary bobbin provided on the service carriage in order to piece with the spun yarn.


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Laying subsidiary windings

B65H 54/34

Securing material to cores or formers

B65H 65/00

{for cans, boxes and other receptacles}
Definition statement

This place covers:

e.g. Removing completed (sliver) cans and/or replacing by empty (sliver) cans.


{Transferring material devices between full and empty cans}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Continuous winding apparatus for winding on two or more winding heads in succession
Definition statement

This place covers:

Configurations of two or more winding heads to be wound on in succession, not provided for in subgroups.

having winding heads arranged on rotary capstan head
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


having two or more winding heads arranged in parallel to each other
Definition statement

This place covers:

With parallel rotary axis.


References
Limiting references

This place does not cover:

Winding heads arranged parallel to each other and arranged on a rotary capstan head

B65H 67/048

having two or more winding heads arranged in series with each other
Definition statement

This place covers:

With in-line rotary axis.


Supplying cores, receptacles, or packages to, or transporting from, winding or depositing stations {(between spinning and winding machines D01H 9/18, e.g. transporting cans D01H 9/185)}
Definition statement

This place covers:

Aspects of supplying and transporting cores or packages not provided for in subgroups.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Supplying cores between spinning and winding machines

D01H 9/18

{Orientating devices}
Definition statement

This place covers:

E.g. correctly positioning cops to be placed on the peg.


{Sorting devices for full/empty packages}
Definition statement

This place covers:

Detection of the winding amount on a cops or bobbin and further routing dependent thereon. media462.png

{Marking or identifying devices for packages}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Supplying or transporting cross-wound packages, also combined with transporting the empty core}
Definition statement

This place covers:

Transport of the cross-wound packages after they have been taken from the winding spindle (B65H 69/04).


{Manipulators with gripping or holding means for transferring the packages from one station to another, e.g. from a conveyor to a creel trolley}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Depositing full or empty bobbins into a container or stacking them}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Removing full or empty bobbins from a container or a stack}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Supplying or transporting empty cores}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Removing or fixing bobbins or cores from or on the vertical peg of trays, pallets or the pegs of a belt}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


References
Limiting references

This place does not cover:

At the unwinding position

B65H 67/02

Automatic end-finding and material-interconnecting arrangements (knot-tying devices B65H 69/00)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Arrangements for taking up waste material by means of pneumatic arrangements, e.g. suction guns

B65H 54/88

Knot-tying devices

B65H 69/00

In piecing arrangements for spinning

D01H 15/00

Special rules of classification

Automatic end-finding at the take-up package after interruption of the ringspinning process are classified in B65H 67/08.

Automatic end-finding in combination with material interconnection in machines other than for winding cross-wound packages, e.g. weaving, carding are classified in B65H 67/08.

{acting after interruption of the winding process, e.g. yarn breakage, yarn cut or package replacement}
Definition statement

This place covers:

Winding process for winding cross wound packages, e.g. in rewinders and open-rotor spinning machines.


Special rules of classification

B65H 67/081 and subgroups relates only to the winding process of winding cross wound packages, not ring spinning process.

{handling the yarn-end of the new supply package}
Definition statement

This place covers:

Finding the yarn-end at the supply package and connecting it to the yarn-end of the cross-wound package.



{end-finding at the take-up package, e.g. by suction and reverse package rotation}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Special rules of classification

When the document contains further technical details with regard to handling the yarn taken from the take-up package, also the class B65H 67/081 is given.

{Preparing supply packages}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Relationships with other classification places

The mechanisms for finding the yarn at the supply package in B65H 67/086 and subgroups are similar to the mechanisms for finding the yarn at the supply package in B65H 67/083.

Special rules of classification

Mechanisms for finding the yarn at the supply package at the (re)winding station with means for further handling of the yarn-end and connecting to the cross-wound package are classified in B65H 67/083.

{Prepositioning the yarn end into the interior of the supply package}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


Methods of, or devices for, interconnecting successive lengths of material; Knot-tying devices {;Control of the correct working of the interconnecting device}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Automatic end-finding and material-interconnecting arrangements

B65H 67/08

Joining

B29C 65/00

Apparatus for joining warp ends

D03J 1/16

For joining, e.g. tying, a complete series of fresh warp threads to the used warp threads

D03J 1/18

Means for fastening cables or ropes to one another or to other objects

F16G 11/00

Splicing of light guides, e.g. by fusion or bonding

G02B 6/255

by means of adhesives
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Joining using adhesives

B29C 65/48

by knotting
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Apparatus for joining warp ends

D03J 1/16

For joining, e.g. tying, a complete series of fresh warp threads to the used warp threads

D03J 1/18

Weavers' tools, e.g. knot-tying tools

D03J 3/00

{the threads are moved in ducts having the form of the wanted knot}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by a fluid}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by splicing {(grommets made by splicing D07B 1/18, auxiliary apparatus for splicing ropes or cables D07B 7/169)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Grommets made by splicing

D07B 1/18

Auxiliary apparatus for splicing ropes or cables

D07B 7/169

Splicing of light guides, e.g. by fusion or bonding

G02B 6/2555

Informative references

Attention is drawn to the following places, which may be of interest for search:

Piecing arrangements in open end spinning machines

D01H 4/48

Piecing arrangements in spinning machines

D01H 15/00

{using pneumatic means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Preparation of the yarn ends}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using mechanical means}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


{Wet splicing, i.e. adding liquid to the splicing room or to the yarn ends preparing rooms}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{using a binding thread, e.g. sewing}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



by welding
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Joining by heating, using heated tools

B29C 65/18

{using ultrasonic means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Joining using ultrasonic vibrations

B29C 65/08

Moistening, sizing, oiling, waxing, colouring or drying filamentary material as additional measures during package formation (applying liquids or other fluent materials to surfaces in general B05)
Definition statement

This place covers:

Moistening, sizing, oiling, waxing, colouring or drying filamentary material as additional measures during package formation.



References
Limiting references

This place does not cover:

Moistening or lubricating threads in knitting machines

D04B 35/24

Informative references

Attention is drawn to the following places, which may be of interest for search:

Applying liquids to surfaces in general

B05

Surface treatment of fibres or filaments from glass, minerals or slags

C03C 25/00

Humidity control, or oiling, of filaments, threads or the like, leaving spinnerettes

D01D 5/096

Moistening, sizing, oiling, waxing, colouring, drying yarns during spinning or twisting

D01H 13/30

Treating warp, e.g. moistening on a weaving loom

D01J1/02

Treating weft on a weaving loom

D01J1/04

Applying liquids, gases or vapours on to textile materials to effect treatment, e.g. washing, dyeing, bleaching, sizing, impregnating

D06B 1/00

Passing individually handled yarns, threads or filaments through liquids, gases or vapours to effect treatment

D06B 3/04

Devices for softening, lubricating or impregnating ropes, cables or strands in rope- or cable-making machines

D07B 7/12

{Abrading, scraping (in general D02J 3/00)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Roughening of fibres

D01G 3/00

Producing crimped or curled fibres, filaments, yarns or threads, at least some of the filaments being simultaneously broken or cut

D02G 1/0246

Modifying the surface of filaments, yarns, threads, cords, ropes or the like by abrading, scraping

D02J 3/02

{Oiling, waxing by applying solid wax cake during spooling}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Applying solids, e.g. wax during spinning or twisting

D01H 13/308

{Oiling, waxing by applying liquid during spooling}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Moistening, sizing, oiling during spinning or twisting by applying fluids, e.g. steam or oiling liquids

D01H 13/306

Stripping waste material from cores or formers, e.g. to permit their re-use
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:

"...waste material being webs, tapes, or filamentary material..."




References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Supplying cores to or transporting from winding or depositing stations

B65H 67/06

Removing waste reserve lengths from spinning spindles

D01H 1/385

Storing webs, tapes, or filamentary material, e.g. on reels (fishing reels A01K 89/00; storing means for record carriers, specially adapted for cooperation with the recording or reproducing apparatus G11B 23/02)
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Fishing reels

A01K 89/00

In metal wire coiling

B21C 47/28

Specially adapted for cooperation with the recording apparatus

G11B 23/02

{Working on damaged packages, e.g. reshaping collapsed cores (working on cores, reels or the like to permit their reuse B65H 75/505)}
Definition statement

This place covers:

Reshaping collapsed cores with the material wound thereon.


References
Limiting references

This place does not cover:

Working on cores, reels or the like (without material wound thereon) to permit their reuse

B65H 75/505

Cores, formers, supports, or holders for coiled, wound, or folded material, e.g. reels, spindles, bobbins, cop tubes, cans (packaging aspects B65D 85/67)
Definition statement

This place covers:

Reels, spindles, bobbins, cop tubes or cans not provided for in subgroups.

Special rules of classification

The following Indexing Codes are to be used in combination with the subgroups:

{specially adapted for winding or storing webs with the confronting layers spaced from each other, e.g. frames for storing nap fabrics}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Kinds or types (B65H 75/18 takes precedence)
Definition statement

This place covers:

Kinds or types not provided for in subgroups.


References
Limiting references

This place does not cover:

Constructional details

B65H 75/18

Flat cores, e.g. cards
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



of circular or polygonal cross-section (cans or receptacles B65H 75/16)
Definition statement

This place covers:

E.g. details of winding shafts or chucks in contact with or near the core or material (web or filamentary).



Relationships with other classification places

Supporting the web roll for unwinding or winding: B65H 16/00, B65H 18/00.

References
Limiting references

This place does not cover:

Expansible winding shafts or chucks

B65H 75/242

without flanges, e.g. cop tubes
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

Dying tubes

D06B 23/042

{Pirns destined for use in shuttles, i.e. with a yarn receiving portion and a thicker base portion, this thicker portion being adapted to be engaged by a spindle in a spinning frame and also being adapted for fitting in a shuttle}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with a single end flange {(e.g. with a conical end flange)}; formed with one end of greater diameter than the barrel
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


with two end flanges
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Ink ribbon spools

B41J 33/003

{covers therefor}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{at least one end flange being shaped to cover the windings}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Reinforcement or protection arrangements for the peripheral edge of the flanges}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{with at least one intermediate flange between the two end flanges}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{with at least one frustoconical end flange}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Winding on frusto-conical cores

B65H 54/103

Cans or receptacles, e.g. sliver cans
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

Supporting devices enclosing the non-rotating package for unwinding: B65H 49/08

Constructional details
Special rules of classification

B65H 75/18 should not be used. Only subgroups are to be used. Several constructional details may be classified.

{Identification means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Barcodes

G06K 1/121, G06K 1/123

Labels with barcode

G09F 3/0297

{End caps, plugs or adapters}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Handles

B65H 2402/412

Printer Roll

B41J 15/042

Wrapping apparatus

B65B 67/085

Plugs, sleeves or caps for packaging

B65D 59/00

{Reinforcing end caps}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Skeleton construction, e.g. formed of wire {(perforated supports for textile materials to be treated D06B 23/042)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Perforated supports for textile materials to be treated

D06B 23/042

collapsible; with removable parts
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:




adjustable in configuration, e.g. expansible
Definition statement

This place covers:

E.g. radially adjustable or expansible reels or cores.


{axially adjustable reels or bobbins}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Core bodies axially expandable

3F058/JA12 (Japanese)

Core bodies axially expandable and of the sliding type

3F058/JA13 (Japanese)

{Expansible spindles, mandrels or chucks, e.g. for securing or releasing cores, holders or packages (expansible mandrels for machine tools B23B 31/00)}
Definition statement

This place covers:

Arrangements of expansible spindels, mandrels or chucks not provided for in subgroups, e.g. media533.pngmedia533.png

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

In Japanese Classification, spindles, mandrels and chucks for securing or releasing cores for winding and unwinding webs

3F052/BA, 3F055/CA B65H 16/00, B65H 18/00

Expansible drum for winding metal wire

B21C 47/30

Expansible mandrels for machine tools

B23B 31/00

Support means for the bobbin inner surfaces

3F056/GC

Support means for the bobbin end sections

3F056/GD

Deformable cores

3F058/JA

Special rules of classification

"Expansion" mechanisms of spindles, mandrels and chucks for securing or releasing cores for winding and unwinding webs are to be classified in B65H 75/242 and not in B65H 16/00 or B65H 18/00.

Securing packages of filamentary material is also classified in B65H 49/36 (unwinding) or B65H 54/543 (winding).

{comprising a fluid pressure actuated elastic member, e.g. a diaphragm or a pneumatic tube}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



{by deformation of an elastic or flexible material}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{by relative rotation of the clamping elements and the supporting spindle or core}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using rollers or rods moving relative to a wedge or cam surface}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{with clamping elements linked to the spindle}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for preventing slipping of winding
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Reels with grooves or grooved elements inhibiting aligned or orderly winding}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements for positively securing ends of material
Definition statement

This place covers:

Securing the start or end of the material (filamentary, web).




{Holding devices to prevent the wound material from unwinding}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


Arrangements to facilitate driving or braking
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Arrangements to facilitate driving by a portable drill}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Arrangements to facilitate severing of material
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


specially adapted or mounted for storing and repeatedly paying-out and re-storing lengths of material provided for particular purposes, e.g. anchored hoses, power cables (retractors for storing flexible hoses as accessories of dental work stands A61G 15/18; vehicle safety belt retractors B60R 22/34; hose-storing devices in apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or portable containers B67D 7/40; clothes-line supports D06F 53/00; spring drums for liftable blinds with horizontal lamellae E06B 9/322; spring drums or tape drums for roll-type closures or roller blinds E06B 9/56; hauling- or hoisting-chains with arrangements for holding electric cables, hoses or the like F16G 13/16; devices for guiding pipes, cables or protective tubing, between relatively movable points, e.g. movable channels, F16L 3/01; flexible rulers or tapes with scales G01B 3/10; electrical features of stored material, see the relevant subclasses, e.g. H02G)
Definition statement

This place covers:

Devices for repeatedly winding and unwinding in which the application in a specific field is of main interest without further interesting details about the device per se.

References
Limiting references

This place does not cover:

Fishing reels

A01K 89/00

Retractors for storing flexible hoses as accessories of dental work stands

A61G 15/18

Vehicle safety belt retractors

B60R 22/34

Winches

B66D 1/00

Hose storing devices in apparatus or devices for transferring liquids from bulk storage containers or reservoirs into vehicles or portable containers

B67D 7/40

Clothes-line supports

D06F 53/00

Spring drums for liftable blinds with horizontal lamellae

E06B 9/322

Spring drums or tape drums for roll-type closures or roller blinds

E06B 9/56

Hauling or hoisting-chains with arrangements for holding electrical cables, hoses or the like

F16G 13/16

Jumbo reels on pipe laying vessels

F16L 1/203

Devices for guiding pipes, cables or protective tubing, between relatively movable points, e.g. movable channels

F16L 3/01

Flexible rulers or tapes with scales

G01B 3/10

Electrical features of stored material, see the relevant subclasses, e.g.

H02G

Informative references

Attention is drawn to the following places, which may be of interest for search:

Devices for guiding or supporting cables in mowers

A01D 34/822

Winch driven watering arrangements, e.g. for watering gardens, sport grounds

A01G 25/095

Retractable leashes, e.g. for dogs

A01K 27/001

Shoe lace tighteners

A43C 7/00

Holders for carriers for hand articles

A45F 5/00

Fire Hose Reels

A62C 33/04

Cord line chalkers

B44D 3/38

Tow ropes

B60D 1/18

Air supply for tyre inflation

B60S 5/04

Waterski winches

B63B 35/816

Cast or safe lines

B63C 9/26

Communication means for working underwater

B63C 11/26

Cable slack preventing in cranes

B66C 13/10

Reeling or storing devices in dispensing liquids

B67D5/365

Flexible barrier members

E01F 13/028

Wheeled apparatus for emptying sewers

E03F 7/10

Cleaning sewers

E03F 9/005

Padlocks

E05B 67/006

Handling reeled pipe or rod units, e.g. flexible drilling pipes

E21B 19/22

In lighting devices

F21V 21/00, F21V 27/00

Storing optical elements

G02B 6/444, G02B 6/4457

Holders for films

G03B 21/321, G03D 13/02

Information storage

G11B 23/02, G11B 23/04

Connectors

H01R 13/72, H01R1/10D

Installing electrical cables

H02G 1/00

Arrangements of cables between relatively movable parts

H02G 11/00

Winding cord in general

H02G 11/02

Protection of telephone cord; Guiding telephone cord; Winding-up telephone cord

H04M 1/15

Special rules of classification

Devices for repeatedly winding and unwinding without essentially involving a core or former internal to a stored package are classified in B65H 75/36 and subgroups.

Devices for repeatedly winding and unwinding involving a core or former internal to a stored package are classified in B65H 75/38 and subgroups

Devices for repeatedly winding and unwinding in which the application in a specific field is of main interest without further interesting details about the device per se are only classified in B65H 75/34.

Stackable reels are additionally classified in B65H 2701/534.

without essentially involving the use of a core or former internal to a stored package of material, e.g. with stored material housed within casing or container, or intermittently engaging a plurality of supports as in sinuous or serpentine fashion
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:




References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Flat cores

B65H 75/06

Optical fiber surplus length storage

G02B 6/444

{with stored material housed within a casing or container (B65H 75/368 takes precedence)}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



References
Limiting references

This place does not cover:

With pulleys around which the material is wrapped

B65H 75/368

{the stored material being coiled}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{with stored package of material loosely hanging on a support, e.g. a hose hanger}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


Special rules of classification

With additional support for the lower part of the coil classify in B65H 75/36

{with pulleys}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


involving the use of a core or former internal to, and supporting, a stored package of material
Definition statement

This place covers:

E.g. non-movable cable or hose reels.


mobile or transportable
Definition statement

This place covers:

Reels that are manually mobile or transportable, e.g. hose reel carts. Contains in general reels on a wheeled manually manoeuvrable carriages.



Relationships with other classification places

Reels attached to or forming part of cars, trucks, trailers, boats and reels forming part of mobile tools, such as electrical appliances: B65H 75/42.

{Carriage with wheels}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{hand-held during use (B65H 75/48, B65H 75/4473 take precedence)}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Limiting references

This place does not cover:

Automatic restoring devices (by spring)

B65H 75/48

Informative references

Attention is drawn to the following places, which may be of interest for search:

Retractable leashes, e.g. for dogs

A01K 27/001

Hand-held fishing apparatus

A01K 89/08

Means for manipulating kiteline

A63H 27/002

attached to, or forming part of, mobile tools, machines or vehicles
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding devices in a suction cleaner

A47L 9/26

{attached to, or forming part of a vehicle, e.g. truck, trailer, vessel}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



Constructional details
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding/unwinding machines with particular frame

242/398 (USPC)

Special rules of classification

If a constructional detail which is not covered by subgroups B65H 75/4402B65H 75/486 is of relevance, symbol B65H 75/44 can be used provided that the document is also classified in one of the subgroups B65H 75/38 - B65H 75/425. Multiple constructional details may be classified.

{Guiding arrangements to control paying-out and re-storing of the material (guides per se B65H 57/00)}
Definition statement

This place covers:

Many of the documents relate to fixed guides, the movable traversing guides being classified in one the subgroups.


Relationships with other classification places

Guides per se: B65H 57/00.

{Traversing devices; means for orderly arranging the material on the drum}
Definition statement

This place covers:

Contains documents in which the guide is moved by the already wound material.


Relationships with other classification places

Traversing per se: B65H 54/28.

{positively driven, e.g. by a transmission between the drum and the traversing device}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



also devices driven by the material being wound


{with a handle on the guide for manual operation}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{with a traversely moving drum}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Also documents with a pivoting drum

{Guiding ribs on the drum}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Relationships with other classification places

Reels with grooves inhibiting aligned or orderly winding: B65H 75/265.

{Arrangements for stopping winding or unwinding; Arrangements for releasing the stop means}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Safety belt with fall arrest reel device

A62B 35/0093

{acting directly on the material}
Definition statement

This place covers:

E.g. lock acting on cable and releasable by pulling the cable


{Manual stop or release button}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Stopping at the end of winding or unwinding}
Definition statement

This place covers:

E.g. mechanical stop attached to the end of the hose.


References
Limiting references

This place does not cover:

Stopping at the end of unwinding by control of the electrical motor

B65H 75/4486

{Manual stop or release button}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{actuated by pulling on or imparting an inclination to the material}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Arrangements for yieldably braking the reel or the material for moderating speed of winding or unwinding}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Brake devices for fishing reels

A01K 89/02

Devices for lowering persons with brake mechanism

A62B 1/08

Winding/unwinding machines with brake (US Classification)

242/396

{acting directly on the material}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Devices for lowering persons with brake sliding on the rope

A62B 1/14

{acting on the reel}
Definition statement

This place covers:

e.g. electromagnetic or rheological brake operating on the reel.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Devices for lowering persons with brake mechanism

A62B 1/08

{with manually adjustable brake pads}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{centrifugally}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



{Arrangements or adaptations to avoid movable contacts or rotary couplings, e.g. by the use of an expansion chamber for a lenght of the cord or hose}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Simultaneous winding and unwinding of the material, e.g. winding or unwinding on a stationary drum while respectively unwinding or winding on a rotating drum using a planetary guiding roller}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{using a planetary assembly coaxially rotating around a central drum}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:



{Arrangements of the frame or housing}
Special rules of classification

Not used. Only use subclasses.

{for releasably or permanently attaching the frame to a wall, on a floor or on a post or the like}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Swivelling attachment}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Foldable or collapsible}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



{Tubular frame}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{Housing enclosing the reel}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{relating to handling of fluids}
Definition statement

This place covers:

Connectors for connecting the (rotating) input of the hose on the reel to the (fixed) fluid supply.


{Arrangements or adaptations for driving the reel or the material (by a spring B65H 75/48)}
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding/unwinding machines with particular drive

US Classification: 242/389

{Electric motors}
Definition statement

This place covers:

Details about driving the reel with an electric motor. Contains also control or detection of the winding or unwinding.



{Fluid motors}
Definition statement

This place covers:

Details about driving the reel with a hydraulic motor. Contains also control or detection of the winding or unwinding.


{Manual drives}
Definition statement

This place covers:

E.g. transmission between the hand-crank and the reel.


{Arrangements or adaptations of the crank}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


{driving by the wheels of the carriage or vehicle}
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Automatic restoring devices {(B65H 75/4418 takes precedence)}
References
Limiting references

This place does not cover:

Arrangements for stopping winding or unwinding;Arrangements for releasing the stop means

B65H 75/4418

Spring-motor for winding (FICLA)

F03G 1/08

Informative references

Attention is drawn to the following places, which may be of interest for search:

Automatic restoring and locks for winding/unwinding (FICLA)

B65H 75/48

Retraction clips

A45F 5/004

Apparatus for physical training

A63B 21/015

Flexible barrier member as used in e.g. airports

E01F 13/028

Unwinding and winding machine with spring motor, locks for winding/unwinding (US Classification)

242/371

Special rules of classification

With a mechanism for stopping winding or unwinding or braking is only classified in B65H 75/4418 and B65H 75/4402 and subgroups.

{Balance reel}
Definition statement

This place covers:

Reels with spring motor to balance a hanging weight (tool) at a certain height


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Tool balancers

B25H 1/0028

{Arrangements or adaptations of the spring motor}
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:



Methods of making reels, bobbins, cop tubes, or the like by working an unspecified material, or several materials
Definition statement

This place covers:

Illustrative examples of subject matter classified in this group:


References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Winding paper cores

B31C

Working on paper cores

B31F

{Working on cores, reels or the like to permit their reuse, e.g. correcting distortion, replacing parts of the core or reel}
Definition statement

This place covers:

Working on the edges of used cores, e.g. to connect several thereof to form new cores.


Driving-gear for devices for forwarding, winding, unwinding, or depositing material, not otherwise provided for
Special rules of classification

Not Used.

Methods, apparatus, or devices for covering or wrapping cores by winding webs, tapes, or filamentary material, not otherwise provided for (forming hollow objects by winding filamentary material on to fusible or soluble cores {B29C 53/56} ; wrapping for the purpose of packaging B65B 11/00; making wound articles of paper B31C)
Definition statement

This place covers:

Only methods and devices for covering or wrapping cores by winding webs, tapes or filamentary material not otherwise provided for.

References
Limiting references

This place does not cover:

Making tubes or metal hoses

B21C 37/12

Coiling wire helically on a mandrel

B21F 3/04

Jacketing or reinforcing with wire

B21F 17/00

Producing tubular article by wrapping (cement)

B28B 21/48

Forming hollow objects by winding filamentary material on to fusible or soluble cores

B29C 53/56

Applying winding materials

B29C 53/8016

Sheathing by winding helically plastic material

B29C 63/105

Shaping by layup on a rotating core

B29C 70/32

Making wound articles of paper

B31C

Wrapping for the purpose of packaging

B65B 11/00

Braiding, lacing

D04C 3/00

Cable stranding

D07B 3/00

Wrapping ropes, cables

D07B 7/14

Hoses with helically wound layers

F16L 11/081

Hoses wound from strips

F16L 11/24

Coating wrapped around a pipe

F16L 58/1063

Manufacturing of air ducts

F24F 13/0245

Twisting optical cables

G02B 6/449

Stranding up conductors

H01B 13/02

Sheathing by winding

H01B 13/26

Winding electrical coils

H01F 41/06

Special rules of classification

In practice documents are only exceptionally classified in B65H 81/00 and subgroups, since they are mostly provided for otherwise.

Covering or wrapping annular or like cores forming a closed or substantially closed figure
Definition statement

This place covers:

E.g. thread buttons.


by feeding material obliquely to the axis of the core
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Covering or wrapping elongated cores
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


by feeding material obliquely to the axis of the core
Definition statement

This place covers:

Illustrative example of subject matter classified in this group:


Combinations of piling and depiling operations, e.g. performed simultaneously, of interest apart from the single operation of piling or depiling as such
Definition statement

This place covers:

aspects which determine that methods and /or devices are able to perform both piling and depiling operations.

References
Limiting references

This place does not cover:

Supplying complete piles or stacks to the support or magazine during continuous separation therefrom

B65H 1/30

Informative references

Attention is drawn to the following places, which may be of interest for search:

Architecture, e.g. modular construction of devices accepting paper currency

G07D 11/40

Special rules of classification

This main-group should be used only for subject-matter not being covered by any of its sub-groups.

Documents which mainly concern depiling e.g. separation aspects, such as constructional details of the separator, and only deals with the possibility of piling as a secondary aspect, should be additionally classified in B65H 3/00 or relevant subgroups.

Documents which mainly concern piling e.g. stacking of articles and only deal with the possibility of depiling as a secondary aspect, should be additionally classified in B65H 29/00 or relevant subgroups.

performed on the same pile or stack
Special rules of classification

Supplying individual articles, either continuous or discontinuous to the support or stack during continuous separation therefrom should be classified in this group or relevant subgroups.

Recirculating articles, i.e. feeding each article to, and delivering it from, the same machine work-station more than once
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Ink-jet or thermal printers for printing on both sides of the material

B41J 3/60

Arrangements for moving an original once or repeatedly through an exposure station in an photographic printing apparatus

G03B 27/6257

Special arrangements in electrographic devices for copying both sides of an original or for copying on both sides of a receiving media

G03G 15/23

Refeeding in connection with double-sided scanning

H04N 1/00572

Subject matter not provided for in other groups of this subclass
Special rules of classification

This group is not used.
