CPC Definition - Subclass F41A

Last Updated Version: 2017.08
FUNCTIONAL FEATURES OR DETAILS COMMON TO BOTH SMALLARMS AND ORDNANCE, e.g. CANNONS; MOUNTINGS FOR SMALLARMS OR ORDNANCE
Definition statement

This place covers:

This subclass covers those features or details which are considered to be of a kind generally applicable to, or to be concerned with intrinsic functions common to, both smallarms and ordnance. Such features or details are classified in this subclass, even if they are stated to be applied only to smallarms or only to ordnance.

Missile propulsion characterised by the use of explosive or combustible propellant charges (projecting missiles without use of explosive or combustible propellant charge F41B; launching rockets or torpedoes F41F 3/00; missile self-propulsion F42B 15/00)
Definition statement

This place covers:

Propulsion is to be interpreted as the launching process of a missile within the barrel. Emphasis is made on the "characterised by", obviously only documents with characteristic propulsion systems are included in this subclass, since every single firearm launches missiles with a pyrotechnic propellant charge.

Relationships with other classification places

Jet propulsion plants

F02K

References
Limiting references

This place does not cover:

Projecting missiles without use of explosive or combustible propellant charge

F41B

Launching rockets or torpedoes

F41F 3/00

Separately loaded propellant charges

F42B 5/38

Missile self-propulsion

F42B 15/00

Hypervelocity missile propulsion using successive means for increasing the propulsive force, e.g. using successively initiated propellant charges arranged along the barrel length; Multistage missile propulsion
Definition statement

This place covers:

Multistage propulsion is generated by the firearm and NOT the missile, usually by using multiple sequentially triggered propellant chambers located at different locations along the barrel.

References
Limiting references

This place does not cover:

Multistage rocket-engine plants

F02K 9/76

Adjusting the range without varying elevation angle or propellant charge data, e.g. by venting a part of the propulsive charge gases, or by adjusting the capacity of the cartridge or combustion chamber {(adjusting the range by using gas-relieving ports in the barrel F41A 21/28)}
Definition statement

This place covers:

Mechanical aspects of the range adjustments.

References
Limiting references

This place does not cover:

Adjusting the range by using gas-relieving ports in the barrel

F41A 21/28

Gun mountings permitting traversing or elevating movement

F41A 27/00

Elevating or traversing control systems for guns

F41G 5/00

Arrangements on projectiles or missiles for range-reducing, range-increasing

F42B 10/00

Recoilless guns, i.e. guns having propulsion means producing no recoil
Definition statement

This place covers:

Guns with means for eliminating recoil by accelerating a mass in a direction opposite to the missile propulsion direction. Usually through Venturi pipes or by causing a part of the propellant gases to be expelled rearwardly to counteract the recoil forces.

References
Limiting references

This place does not cover:

Stocks specially adapted for recoil reduction

F41C 23/06

Recoilless rocket launchers adapted to be carried and used by a person, e.g. bazookas

F41F 3/045

Informative references

Attention is drawn to the following places, which may be of interest for search:

Cartridge ammunition for recoilless guns

F42B 5/05

a counter projectile being used to balance recoil
Definition statement

This place covers:

The counter projectile can be a disintegrating projectile, e.g. comprising liquid or powder.

Breech mechanisms, e.g. locks
Definition statement

This place covers:

The breech mechanism, i.e. the breech block itself and the mechanism enabling the opening and closing and if applicable the locking of the breech. Furthermore the mounting of the breech block and mechanism is covered.

References
Limiting references

This place does not cover:

Mechanisms or systems operated by propellant charge energy for automatically opening the lock

F41A 5/00

Auxiliary mechanisms for bringing the breech-block or bolt or the barrel to the starting position before automatic firing

F41A 7/00

Ramming arrangements, the breech-block itself being the rammer

F41A 9/40

Mounting of cartridge ejectors on or within the bolt

F41A 15/14

Mounting of cartridges ejectors in the breech housing

F41A 15/16

Safeties for locking the breech-block or bolt in a safety position

F41A 17/42

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Breech

The rear part of the bore of a gun barrel, especially the opening that permits the projectile to be inserted at the rear of the bore.

Breech housings or frames; Receivers
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Weapons manufactured from plastics:

B29L 2031/777

Bolt buffer or recuperator means
Definition statement

This place covers:

The primary mechanism in automatic and semi-automatic firearms for bringing the bolt or breech block back into closed position after a recoil cycle.

References
Limiting references

This place does not cover:

Auxiliary mechanisms for bringing the breech-block or bolt or the barrel to the starting position before automatic firing

F41A 7/00

Gun mounting permitting recoil or return to battery

F41A 25/00

Mechanisms or systems operated by propellant charge energy for automatically opening the lock
Definition statement

This place covers:

Mechanisms for opening the lock of semi-automatic and automatic firearms using ONLY the energy provided by the propellant charge during the launching of the projectile, i.e. autonomous systems, independent from an auxiliary source of energy.

References
Limiting references

This place does not cover:

Auxiliary mechanisms for bringing the breech-block or bolt or the barrel to the starting position before automatic firing

F41A 7/00

Internally powered drives for feeding and loading ammunition

F41A 9/49

Externally power or control systems

F41A 9/50

Informative references

Attention is drawn to the following places, which may be of interest for search:

Bolt buffers or recuperator means

F41A 3/78

Gun mounting permitting recoil or return to battery

F41A 25/00

having an accelerator lever acting on the breech-block or bolt during the opening movement
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delaying breech opening movements

F41A 3/62

having a movable inertia weight {, e.g. for storing energy}
Definition statement

This place covers:

The energy is accumulated during the rearward of the bolt or barrel after the lock has been opened by the recoil or due to gas operation, consequently implying that the stored energy is used for closing the lock

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Delaying breech opening means

F41A 3/62

Energy accumulator systems

F41A 5/32

Arrangements or systems for bleeding the gas from the barrel (F41A 5/20 - F41A 5/24 take precedence)
References
Limiting references

This place does not cover:

Gas operated mechanisms or systems operated by propellant charge energy for automatically opening the lock using a gas piston arranged concentrically around the barrel

F41A 5/20

Gas operated mechanisms or systems operated by propellant charge energy for automatically opening the lock by direct action of gas pressure on bolt or locking elements

F41A 5/24

Evacuating combustion gas from barrels

F41A 13/06

Barrels, gun tubes, muzzle attachments, barrel mounting means

F41A 21/00

Energy accumulator systems, i.e. systems for opening the breech-block by energy accumulated during barrel or gas piston recoil
Definition statement

This place covers:

Implies a delayed or staged lock opening movement. The recoil or gas piston movement is accumulated, and the accumulated energy is used in a second stage to open the lock, after partial or full completion of the recoil/piston movement.

References
Limiting references

This place does not cover:

Recoil operated opening with moveable inertia weigth for storing energy

F41A 5/10

Auxiliary mechanisms for bringing the breech-block or bolt or the barrel to the starting position before automatic firing; Drives for externally-powered guns; Remote-controlled gun chargers
Definition statement

This place covers:

Mechanisms for automatically cycling a firearm independent of the propellant charge for bringing the moving components back into firing position enabling the choice of firing rate.

References
Limiting references

This place does not cover:

External power or control systems for feeding and loading

F41A 9/50

Shot velocity control

F41A 19/03

Feeding or loading of ammunition ({conveying ammunition through pipes by the action of flowing gases B65G 51/025} ; adaptations for feeding or loading missiles from magazines in air guns F41B 11/50); Magazines; Guiding means for the extracting of cartridges (cartridge extractors or ejectors F41A 15/00)
Definition statement

This place covers:

Devices an mechanisms for conveying the ammunition from its storage location or transport unit to the firing position.

References
Limiting references

This place does not cover:

Cartridge extractors or ejectors

F41A 15/00

Adaptations for feeding or loading missiles from magazines in air guns

F41B 11/50

Informative references

Attention is drawn to the following places, which may be of interest for search:

Conveying ammunition through pipes by the action of flowing gases

B65G 51/025

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Feeding

Devices or mechanisms for sequentially bringing missiles from an external storage (magazine, belt, box) into the gun frame/casing/housing/receiver

Loading

Devices or mechanisms for sequentially bringing missiles into the firing chamber

Ramming

Devices or mechanisms for forcing a projectile into the constriciting area of the chamber or the beginning of the barrel itself

Feeding of unbelted ammunition
Definition statement

This place covers:

Feeding of unconnected cartridges, projectiles or propelling charges one by one or in batches.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Transporting ammunition through pipes by means of fluid medium pressure pneumatically

B65G 51/025

using endless-chain belts carrying a plurality of ammunition
Definition statement

This place covers:

The endless belt is only used to move UNBELTED ammunition from the storage magazine into the firearm

References
Limiting references

This place does not cover:

Feeding of belted ammunition

F41A 9/29

Feeding of belted ammunition
Definition statement

This place covers:

Feeding of ammunition strings having cartridges carried by a textile band or by carrier units each holding one cartridge, the carrier units being sequentially connected to each other by connecting elements or connected to each other by belt links, each belt link holding one cartridge and embracing the previous or subsequent cartridge.

References
Limiting references

This place does not cover:

Belt link collectors or catchers

F41A 9/60

Magazines with belt link collectors and catchers

F41A 9/81

Informative references

Attention is drawn to the following places, which may be of interest for search:

Feeding of unbelted ammunition with an endless belt conveyor

F41A 9/04

Feeding of ammunition mounted on solid racks, the racks passing through the gun (Hotchkiss type, Japanese Type 92 HMG)

F42B 39/08

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Cartridge stripping

removing belt link from the cartridge

Internally-powered drives, i.e. operated by propellant charge energy, e.g. couplings, clutches, energy accumulators
Definition statement

This place covers:

Mechanisms wherein the propellant charge energy is used for particular ammunition loading and feeding.

References
Limiting references

This place does not cover:

Mechanisms or systems operated by propellant charge energy for automatically opening the lock

F41A 5/00

External power or control systems
Definition statement

This place covers:

Mechanisms wherein an external drive is used for particular ammunition loading and feeding.

References
Limiting references

This place does not cover:

Auxiliary mechanisms for bringing the breech-block or bolt or the barrel to the starting position before automatic firing; Drives for externally-powered guns; Remote-controlled gun chargers

F41A 7/00

Charged-condition indicators, i.e. indicating the presence of a cartridge in the cartridge chamber
References
Limiting references

This place does not cover:

Magazines having means for indicating the number of cartridges left in the magazine, e.g. last-round indicators

F41A 9/62

Last round safeties

F41A 17/40

Empty-cartridge-case or belt-link collectors or catchers (F41A 9/81 takes precedence)
References
Limiting references

This place does not cover:

Cartridge stripping means in sprocket transporters

F41A 9/31

Cartridge stripping means in reciprocating slide transporters

F41A 9/33

Magazines for belted ammunition having provision for collecting belt links or empty cartridge cases

F41A 9/81

having means for indicating the number of cartridges left in the magazine, e.g. last-round indicators (last-round safeties F41A 17/40)
References
Limiting references

This place does not cover:

Charge condition indicator

F41A 9/53

Last round safeties

F41A 17/40

Assembly or disassembly features; Modular concepts; Articulated or collapsible guns (F41A 3/64, F41A 19/10 - F41A 19/15, F41A 21/48, F41A 25/26 take precedence)
Definition statement

This place covers:

Features and mechanisms and methods for assembling and dissasembling a firearm.

Modular weapon family concepts.

Articulation and collapsing of firearms for the PURPOSE of storage or transport.

References
Limiting references

This place does not cover:

Breakdown breech mechanisms

F41A 3/58

Mounting of breech-blocks; Accessories for breech-blocks or breech-block mountings

F41A 3/64

Triggers; Trigger mountings

F41A 19/10

Modular firing mechanism units

F41A 19/15

Barrel mounting means, e.g. releasable mountings for replaceable barrels

F41A 21/48

Assembling or dismounting recoil elements or systems

F41A 25/26

Folding or telescopic stocks or stock parts

F41C 23/04

Cooling or heating systems; Blowing-through of gun barrels; Ventilating systems
Definition statement

This place covers:

Active systems specially adapted for cooling or heating firearm components, in particular the barrel and the firing chamber.

References
Limiting references

This place does not cover:

Barrels and gun tubes with fins or fins for cooling

F41A 21/02

Evacuating combustion gas from barrels (F41A 13/10 takes precedence)
References
Limiting references

This place does not cover:

Arrangements or systems for bleeding the gas from the barrel

F41A 5/26

Blowers or turbines for evacuating or cooling guns, e.g. driven by combustion gas pressure or recoil

F41A 13/10

Systems for cooling the outer surface of the barrel (F41A 13/10, F41A 21/24 take precedence)
References
Limiting references

This place does not cover:

Blowers or turbines for evacuating or cooling guns, e.g. driven by combustion gas pressure or recoil

F41A 13/10

Barrels or gun tubes with fins or ribs, e.g. for cooling

F41A 21/24

Informative references

Attention is drawn to the following places, which may be of interest for search:

Insulation jackets & protective jackets for barrels

F41A 21/44

Cartridge extractors, i.e. devices for pulling cartridges or cartridge cases at least partially out of the cartridge chamber; Cartridge ejectors, i.e. devices for throwing the extracted cartridges or cartridge cases free of the gun (F41A 9/54, {F41C 9/08} take precedence; {Means for removing duds or misfires in rocket throwers F41F 3/058})
Definition statement

This place covers:

Devices, mechanisms or tools for removing a spent cartridge case or a dud from the firing chamber or for unloading a cartridge from the chamber.

References
Limiting references

This place does not cover:

Blowers or turbines for evacuating or cooling guns, e.g. driven by combustion gas pressure or recoil

F41A 9/54

Barrels or gun tubes with fins or ribs, e.g. for cooling

F41C 9/08

Means for removing duds or misfires in rocket throwers

F41F 3/058

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Dud:

Cartridge, or separately loaded projectile or case, remaining stuck in the firing chamber after a misfire

Spent cartridge case:

case remaining after the projectile was launched

Safety arrangements, e.g. safeties
Definition statement

This place covers:

Devices and mechanism covering all aspects of firearm safety, including:

preventing unauthorised use

blocking or rendering ineffective diverse functional parts of the firearm to prevent inadvertent firing

inhibiting firing in a particular direction

preventing cook off or hang fire

preventing release of magazine

last round safeties

Electric or electromechanical safeties (F41A 17/04, F41A 17/08 take precedence)
Definition statement

This place covers:

Includes electric or electromagnetic means for preventing or enabling the use of a firearm. Also includes the remote control or a firearm, in the sense that a central control instance can block or release the use of the firearm. Also includes remote monitoring of firearm movement and/or usage. Further includes passive, post-incident safety means such as a black box data recording.

References
Limiting references

This place does not cover:

Safeties of the combination-lock type

F41A 17/04

Safeties for inhibiting firing in a specified direction, e.g. at a friendly person or at a protected area

F41A 17/08

Remote triggering of a firearm

F41A 19/08

Electric firing mechanisms

F41A 19/56

{comprising a transponder}
Definition statement

This place covers:

Includes means for remote weapon control and monitoring.

Double-loading prevention
Definition statement

This place covers:

Features to avoid jamming in the cartridge chamber caused by an attempt to load a second cartridge in an already loaded chamber.

Hang-fire prevention
Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Hang fire

an unexpected delay between the triggering of a firearm and the ignition of the propellant

Magazine safeties
References
Limiting references

This place does not cover:

Safety plugs, e.g. for plugging-up cartridge chambers

F41A 17/44

locking the gun {automatically} in a safety condition when the magazine is empty or removed {(F41A 17/44 takes precedence)}
Definition statement

This place covers:

Last round safety for magazine fed smallarm, the follower of the magazine activating or acting on a gun-locking element such as a bolt or pistol slide. Means for preventing a loaded cartridge to be fired when the magazine is removed from the smallarm.

References
Limiting references

This place does not cover:

Safety plugs, e.g. for plugging-up cartridge chambers

F41A 17/44

{Magazine mountings, e.g. for} locking the magazine in the gun
References
Limiting references

This place does not cover:

Safety plugs, e.g. for plugging-up cartridge chambers

F41A 17/44

Last-round safeties (F41A 17/34 takes precedence)
Definition statement

This place covers:

Means for setting an automatic, non-magazine-fed and usually medium or large calibre gun's feeding, ramming, loading and/or firing mechanism into a safe/inactive configuration when the last cartridge is chambered or fired, e.g. in Gatling type guns.

References
Limiting references

This place does not cover:

Locking a smallarm in a safety condition when the magazine is empty or removed

F41A 17/34

Firing or trigger mechanisms; Cocking mechanisms
Definition statement

This place covers:

Mechanisms or systems for firing, i.e. initiating the ignition of the propellant charge by mechanical, fluid-operated, pyrotechnic, optical or electric means.

Cocking mechanisms, i.e. for bringing mechanical firing means in a pre-tensioned, ready to fire state (cocked).

Further includes means for controlling number of shots fired, firing rate and synchronisation.

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

Sear:

the part of the trigger mechanism which holds the hammer or striker back until the correct amount of pressure has been applied to the trigger; at which point the hammer or striker is released to discharge the weapon. The sear may be a separate part or can be a surface incorporated into the trigger

DA

Double action trigger performs the action of cocking during the initial trigger pull movement and releases the hammer or striker at the pressure point

DA/SA

Double action / Single action Double action for first shot and single action for subsequent shots

DAO

Double action onlyDouble action for all shots

SA

Single actiontrigger only performs the action of releasing the hammer or striker

Cocking

bringing mechanical firing means in a pre-tensioned, ready to fire state (cocked)

Burst limiters (F41A 19/67 takes precedence)
Definition statement

This place covers:

Means for allowing a predefined number of of rounds to be fired upon a single trigger action.

References
Limiting references

This place does not cover:

Arrangements for the selection of automatic and semi-automatic fire in bolt action guns having a sliding striker

F41A 19/33

Arrangements for the selection of automatic and semi-automatic fire in bolt action guns having a hammer

F41A 19/46

Burst limiters

F41A 19/67

remote actuated; lanyard actuated
References
Limiting references

This place does not cover:

Remote safing and monitoring of firearms

F41A 17/06

Hair-trigger mechanisms
Definition statement

This place covers:

A trigger allowing a shooter to have a greatly reduced trigger pull (the resistance of the trigger) while maintaining a degree of safety in the field

with single-trigger firing possibility
Definition statement

This place covers:

One trigger can cause the firing of more than one barrel

Double-trigger arrangements having the possibility of single-trigger actuation
Definition statement

This place covers:

One trigger per barrel is present, but the shooter has the choice of firing each barrel with its dedicated trigger, or both at the same time by actuation of a single trigger (after appropriate setting).

Electric firing mechanisms (F41A 17/10, F41A 17/12 take precedence)
Definition statement

This place covers:

Means for electrically releasing mechanical firing means or for firing electrical primers in cartridges. Further includes mechanisms where the primer charge is ignited optically, e.g. by a laser or intense light.

References
Limiting references

This place does not cover:

Firing mechanisms with elevation stop

F41A 17/10

Firing mechanisms with anti-canting safety

F41A 17/12

Barrels; Gun tubes; Muzzle attachments; Barrel mounting means (F41A 25/00 takes precedence; barrel attachments for firing grenades or riot-control ammunition from smallarms F41C 27/06)
Definition statement

This place covers:

Includes barrels, tubes; attachments and mounting means therefore. The cartridge chamber or firing chamber is an integral part of the barrel, except for, e.g. revolver type guns and certain block action guns.

References
Limiting references

This place does not cover:

Gun mountings permitting recoil or return to battery, e.g. gun cradles; Barrel buffers or brakes

F41A 25/00

Checking of barrels

F41A 31/02

Rocket launcher tubes

F41F 3/04

Composite barrels, i.e. barrels having multiple layers, e.g. of different materials
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Manufacture with plastics

B29L 2031/777

Insert barrels, i.e. barrels for firing reduced calibre ammunition and being mounted within the normal barrels
References
Limiting references

This place does not cover:

Adaptations for training

F41A 33/00

Barrels or gun tubes characterised by the material (F41A 21/02 takes precedence)
References
Limiting references

This place does not cover:

Composite barrels, i.e. barrels having multiple layers, e.g. of different materials

F41A 21/02

Informative references

Attention is drawn to the following places, which may be of interest for search:

Making rifle and gun barrels

B21C 37/152

Barrels or gun tubes with fins or ribs, e.g. for cooling (F41G 1/42 takes precedence)
References
Limiting references

This place does not cover:

Cooling or heating systems

F41A 13/00

Tube sights; Bar sights

F41G 1/42

specially adapted for recoil reinforcement, e.g. for training purposes
Definition statement

This place covers:

Includes blank firing arrangements

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Bullet catchers not fixed to a fire arm

F41J 13/00

Bullet traps in rifle grenades

F42B 30/06

Silencers
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Mountings for muzzle attachments incl. suppressors or silencers

F41A 21/325

Muzzle attachments or glands (F41A 21/26, F41A 21/30, F41A 21/46 take precedence{; for projectile velocity measurements G01P 3/665, G01P 3/685})
References
Limiting references

This place does not cover:

Barrels specially adapted for recoil reinforcement, e.g. for training purposes

F41A 21/26

Silencers

F41A 21/30

Barrels having means for separating sabots from projectiles

F41A 21/46

Tube sights; Bar sights

F41G 1/42

Informative references

Attention is drawn to the following places, which may be of interest for search:

Blankfiring attachments

F41A 21/40

Device using electric or magnetic means for projectile velocity measurements

G01P 3/665

Device using optical means for projectile velocity measurements

G01P 3/685

Chokes for shotguns{, e.g. automatic chokes}
Definition statement

This place covers:


Lampel, Mahrholdt, "Waffenlexikon", 9th edition, DE, München, BLV Verlagsgesellschaft, 1981, S. 56

A: normal choke

B: Schlegelmich choke, constricting choke

C: Nischen , jug or recess choke

D: Glockenchoke, bell choke, diverging choke

E, F: Skeet chokes

Insulation jackets; Protective jackets
References
Informative references

Attention is drawn to the following places, which may be of interest for search:

see for cooling aspects such as cooling mantles also F41A 13/12

Gun mountings, e.g. on vehicles; Disposition of guns on vehicles (F41A 25/00, F41A 27/00 take precedence)
Definition statement

This place covers:

All mountings of firearms, fixed or mobile, except for the ones specifically designed for return to battery and the ones permitting traversing or elevating movement (see precedence, F41A 25/00 and F41A 27/00). It includes locking means between gun an mounting, mountings without wheels (conventional mono-, bi- or tripods, test mounts and bench rests), mountings permitting the gun to retract into a hidden position, wheeled mountings (the wheels being mounted directly on the gun), mounted on vehicles, mounts for transport and adjustments means of the platform position.

References
Limiting references

This place does not cover:

Gun mountings permitting recoil or return to battery, e.g. gun cradles; Barrel buffers or brakes

F41A 25/00

Gun mountings permitting traversing or elevating movement, e.g. gun carriages

F41A 27/00

Informative references

Attention is drawn to the following places, which may be of interest for search:

Central pivot bearings (for gun mountings)

F41A 27/14

Gun mounting on aircraft

B64D 7/00

Testing mounts
Definition statement

This place covers:

Rests holding the firearm so as to enable stabilised shooting, includes both test shooting mounts and shooting rests, i.e. for bench rest shooting

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Testing mounts for checking gun barrels

F41A 31/02

Shooting stands, e.g. for firing hunting rifles from trees

A01M 31/02

Rests for supporting smallarms in non-shooting position (racks for storage A47B 81/00; racks in vehicles {B60R 7/14})
Definition statement

This place covers:

Rests for holding the firearm in a fixed position for displaying, inspecting, adjusting, maintaining, repairing or cleaning of the firearm.

References
Informative references

Attention is drawn to the following places, which may be of interest for search:

Key operated safeties

F41A 17/02

Combination lock safeties

F41A 17/04

Cabinets or racks specially adapted for other particular purposes, e.g. for storing guns or skis

A47B 81/00

Disposition of racks for weapons inside vehicles

B60R 7/14

For carrying firearms on the body

F41C 33/00

Containers for carrying smallarms, boxes/gun cases

F41C 33/06

Wheeled-gun mountings; Endless-track gun mountings
Definition statement

This place covers:

The wheels are directly mounted on the gun or gun cradle.

Trail spades
Definition statement

This place covers:


GB2455651

Gun mountings permitting recoil or return to battery, e.g. gun cradles; Barrel buffers or brakes (recoilless guns F41A 1/08)
Definition statement

This place covers:

Gun mounts permitting travel of the gun from the shooting position into full recoil position along a bearing and returning to battery position, including spring, fluid, friction operated systems as well as hybrids thereof. It further includes bearings and assembly/disassembly features peculiar thereto.

References
Limiting references

This place does not cover:

Recoilless guns, i.e. guns having propulsion means producing no recoil

F41A 1/08

Gun mountings permitting traversing or elevating movement, e.g. gun carriages
Definition statement

This place covers:

Mechanical aspects of gun mounts permitting supported pointing of the gun for laying the gun, i.e. in the position to fire the gun and hitting the target.

References
Limiting references

This place does not cover:

Monopods

F41A 23/04

Bipods

F41A 23/08

Tripods

F41A 23/12

Aiming means; Laying means

F41G 3/00

Elevation or traversing control systems for guns

F41G 5/00

Cleaning or lubricating arrangements (injecting fluids into barrels or cartridge chambers F41A 13/04{; ammunition for cleaning purposes F42B 5/24})
References
Limiting references

This place does not cover:

Injecting fluids into barrels or cartridge chambers

F41A 13/04

Ammunition for cleaning purposes

F42B 5/24

Informative references

Attention is drawn to the following places, which may be of interest for search:

Cleaning of hollow objects in general

B08B 9/00

Pigs or moles, i.e. devices movable in a pipe or conduit with or without self-contained propulsion means

F16L 55/26

Scrapers or cleaning rods
Definition statement

This place covers:

Includes flexible cleaning devices for gun barrels, i.e. flexible wires or rope.

Lubricating, oiling or greasing means, e.g. operating during use
References
Limiting references

This place does not cover:

Projectiles or cartridges for cleaning cooling or lubricating

F42B 5/24

Testing arrangements (testing mounts F41A 23/16)
Definition statement

This place covers:

All arrangements, devices, systems for testing the functionality of a firearm, except for testing of sighting, aiming and laying means

References
Limiting references

This place does not cover:

Testing mounts

F41A 23/16

Checking or testing of ammunition

F41B35/00

Devices for testing or checking of sighting means

F41G 1/54

Devices for testing or checking of aiming means

F41G 3/32

Apparatus for testing or checking of laying means

F41G 5/26

for checking gun barrels
References
Limiting references

This place does not cover:

Devices for testing or checking of sights (parrallelity with the barrel)

F41G 1/54

Synonyms and Keywords

bore sighting devices

Adaptations for training (adaptations of barrels for recoil reinforcement F41A 21/26); Gun simulators (teaching or practice apparatus for gun-aiming or gun-laying F41G 3/26{; shooting games A63F 9/02; military simulation G09B 9/003})
Definition statement

This place covers:

Adaptations of firearms for use in training without live ammunition or weapons specially adapted for training and simulation only.

References
Limiting references

This place does not cover:

Insert barrels

F41A 21/10

Adaptations of barrels for recoil reinforcement

F41A 21/26

Shooting or hurling games

A63F 9/02

Teaching or practice apparatus for gun-aiming or gun-laying

F41G 3/26

Simulators for teaching or training purposesfor military purposes and tactics

G09B 9/003

Informative references

Attention is drawn to the following places, which may be of interest for search:

Firecrackers

F42B 4/04

Hand thrown impact-exploded noise makers

F42B 4/16

Light- or radiation-emitting guns{; Light- or radiation-sensitive guns; Cartridges carrying light emitting sources, e.g. laser}
Definition statement

This place covers:

Includes:

  • separate light producing units fitted in the barrel of an existing gun and
  • externally mounted light beam emitting units

(torch-like)

References
Limiting references

This place does not cover:

Cartridges carrying light emitting sources

F42B 8/00

Military or tactic simulation systems

G09B 9/003

Informative references

Attention is drawn to the following places, which may be of interest for search:

Teaching or practice apparatus for gun laying or gun aiming

F41G 3/26

Active targets transmitting infrared radiation

F41J 5/02

Infrared hit indicating systems

F41J 5/08

Glossary of terms

In this place, the following terms or expressions are used with the meaning indicated:

MILES: Multiple Integrated Laser Engagement System

Accessories or details not otherwise provided for
Special rules of classification

Residual group for F41A 1/00-F41A 33/00, particularly listing common accessories such as dust covers, e.g. ejection port or muzzle covers, or adaptations for ambidextrous use of firearms.
